M317F
Excavator
35 specifications
1 / 5
Image 1 of 5
Specifications
26 data points
Operating Specifications
| Operating Weight | 14,793 lb |
|---|---|
| Fuel Capacity | 12.7 gal |
| Hydraulic Pump Flow Capacity | 7.7 gal/min |
| Hydraulic System Fluid Capacity | 18.5 gal |
| Hydraulic System Relief Valve Pressure | 3,002 psi |
| Engine Oil Capacity | 1.4 gal |
| Operating Voltage | 12 V |
| Alternator Supplied Amperage | 55 A |
Engine
| Engine Model | 403-15 |
|---|---|
| Gross Power | 27.8 hp |
| Net Power | 26.6 hp |
| Max Torque | 68 lb-ft |
Dimensions
| Height - Top of Cab | 96 in |
|---|---|
| Tail Swing Radius | 57 in |
| Width to Outside of Tracks | 57 in |
Undercarriage
| Ground Pressure | 5 psi |
|---|---|
| Number of Track Rollers per Side | 4 |
| Max Travel Speed | 2.3 mph |
| Shoe Size | 9 in |
Boom/Stick Excavator Option 1
| Max Digging Depth | 119 in |
|---|---|
| Max Reach Along Ground | 187 in |
| Max Loading Height | 127 in |
| Max Cutting Height | 173 in |
| Shipping Length of Unit | 172 in |
| Shipping Height of Unit | 96 in |
Swing Mechanism
| Swing Speed | 10 rpm |
|---|
