TB23R
Mini Excavator
29 specifications
1 / 5
Image 1 of 5
Specifications
37 data points
Operating Specifications
| Operating Weight | 9,480 lb |
|---|---|
| Fuel Capacity | 18.0 gal |
| Hydraulic Pump Flow Capacity | 23.8 gal/min |
| Hydraulic System Fluid Capacity | 25.9 gal |
| Hydraulic System Relief Valve Pressure | 3,191 psi |
| Operating Voltage | 12 V |
| Alternator Supplied Amperage | 65 A |
| Engine Oil Capacity | 3.8 gal |
| Cooling System Fluid Capacity | 3.6 gal |
Engine
| Engine Model | 404-22c |
|---|---|
| Displacement | 2 in³ |
| Power Measured @ | 2,200 rpm |
| Gross Power | 46.4 hp |
| Torque Measured @ | 1,600 rpm |
| Max Torque | 101 lb-ft |
Dimensions
| Ground Clearance | 15 in |
|---|---|
| Height - Top of Cab | 102 in |
| Length of Track on Ground | 73 in |
| Tail Swing Radius | 40 in |
| Width to Outside of Tracks | 78 in |
| Removal Counterweight Clearance | 28 in |
| Digging Depth | 141 in |
| Digging Reach | 222 in |
Undercarriage
| Ground Pressure | 4 psi |
|---|---|
| Track Gauge | 62 in |
| Number of Track Rollers per Side | 4 |
| Max Travel Speed | 2.5 mph |
| Shoe Size | 16 in |
| Drawbar Pull | 10,858 lb |
Boom/Stick Excavator Option 1
| Max Digging Depth | 132 in |
|---|---|
| Max Reach Along Ground | 222 in |
| Max Vertical Wall Digging Depth | 88 in |
| Max Loading Height | 151 in |
| Shipping Length of Unit | 202 in |
| Max Cutting Height | 206 in |
| Shipping Height of Unit | 102 in |
Swing Mechanism
| Swing Speed | 10 rpm |
|---|
