Takeuchi
Komatsu
PC20R-8
Mini Excavator
47 specifications
1 / 5
Image 1 of 5
Specifications
29 data points
Operating Specifications
| Operating Weight | 5,732 lb |
|---|---|
| Fuel Capacity | 8.0 gal |
| Hydraulic Pump Flow Capacity | 18.6 gal/min |
| Hydraulic System Fluid Capacity | 10.1 gal |
| Hydraulic System Relief Valve Pressure | 3,046 psi |
| Operating Voltage | 12 V |
| Engine Oil Capacity | 0.9 gal |
| Cooling System Fluid Capacity | 1.0 gal |
Engine
| Engine Model | 3TNV76 |
|---|---|
| Displacement | 204 in³ |
| Power Measured @ | 2,300 rpm |
| Net Power | 18.7 hp |
| Max Torque | 50 lb-ft |
Dimensions
| Ground Clearance | 11 in |
|---|---|
| Height - Top of Cab | 97 in |
| Length of Track on Ground | 56 in |
| Tail Swing Radius | 32 in |
| Width to Outside of Tracks | 55 in |
| Removal Counterweight Clearance | 20 in |
Undercarriage
| Ground Pressure | 5 psi |
|---|---|
| Max Travel Speed | 2.7 mph |
| Shoe Size | 10 in |
Boom/Stick Excavator Option 1
| Max Digging Depth | 101 in |
|---|---|
| Max Reach Along Ground | 172 in |
| Max Vertical Wall Digging Depth | 86 in |
| Max Loading Height | 104 in |
| Shipping Length of Unit | 155 in |
| Max Cutting Height | 166 in |
| Shipping Height of Unit | 97 in |
