302.5C
Mini Excavator
89 specifications
1 / 5
Image 1 of 5
Specifications
47 data points
Operating Specifications
| Operating Weight | 5,589 lb |
|---|---|
| Fuel Capacity | 9.3 gal |
| Hydraulic Pump Flow Capacity | 15.8 gal/min |
| Hydraulic System Fluid Capacity | 7.7 gal |
| Hydraulic System Relief Valve Pressure | 3,046 psi |
| Operating Voltage | 12 V |
| Alternator Supplied Amperage | 40 A |
| Engine Oil Capacity | 1.0 gal |
| Cooling System Fluid Capacity | 1.1 gal |
Engine
| Engine Model | 3D78AE-3FA |
|---|---|
| Displacement | 73 in³ |
| Power Measured @ | 2,600 rpm |
| Gross Power | 26.7 hp |
| Net Power | 23.3 hp |
| Number of Cylinders | 3 |
| Aspiration | Natural |
| Torque Measured @ | 1,600 rpm |
| Max Torque | 54 lb-ft |
Dimensions
| Height - Top of Cab | 97 in |
|---|---|
| Length of Track on Ground | 53 in |
| Tail Swing Radius | 49 in |
| Width to Outside of Tracks | 54 in |
| Removal Counterweight Clearance | 22 in |
Undercarriage
| Ground Pressure | 2 psi |
|---|---|
| Track Gauge | 44 in |
| Number of Track Rollers per Side | 3 |
| Max Travel Speed | 2.7 mph |
| Shoe Size | 10 in |
| Number of Shoes per Side | 38 |
Boom/Stick Excavator Option 1
| Max Digging Depth | 94 in |
|---|---|
| Max Reach Along Ground | 168 in |
| Max Vertical Wall Digging Depth | 76 in |
| Max Loading Height | 109 in |
| Shipping Length of Unit | 168 in |
| Max Cutting Height | 159 in |
| Shipping Height of Unit | 97 in |
Bucket
| Reference Bucket Capacity | 0.10 yd³ |
|---|---|
| Maximum Bucket Capacity | 0.20 yd³ |
| Minimum Bucket Capacity | 0.10 yd³ |
Swing Mechanism
| Swing Speed | 9 rpm |
|---|
Boom/Stick Excavator Option 2
| Max Digging Depth | 101 in |
|---|---|
| Max Cutting Height | 166 in |
| Max Loading Height | 117 in |
| Max Vertical Wall Digging Depth | 86 in |
| Max Reach Along Ground | 178 in |
| Shipping Height of Unit | 97 in |
| Shipping Length of Unit | 170 in |
