JCB
Fendt
817
Tractor
23 specifications
JCB
FASTRAC 8250
- Operating Weight
- 23,457 lb
- Displacement
- 507 in³
- Power Measured @
- 2,000 rpm
- Gross Power
- 280.0 hp
1 / 5
Image 1 of 5
Specifications
24 data points
Operating Specifications
| Operating Weight | 23,457 lb |
|---|---|
| Fuel Capacity | 158.6 gal |
| 3 Point Hitch Lift Capacity @ 24 inches | 22,046 lb |
| 3 Point Hitch Type | Cat. III |
| Alternator Supplied Amperage | 150 A |
| Operating Voltage | 12 V |
| Hydraulic System Fluid Capacity | 47.6 gal |
Engine
| Engine Model | QSB |
|---|---|
| Displacement | 507 in³ |
| Power Measured @ | 2,000 rpm |
| Gross Power | 280.0 hp |
| Number of Cylinders | 6 |
| Aspiration | Turbocharged intercooled |
| Torque Rise | 29.0 % |
Hydraulic System
| Pump Flow Capacity | 55.0 gal/min |
|---|---|
| Relief Valve Pressure | 3,045 psi |
Dimensions
| Ground Clearance | 19 in |
|---|---|
| Wheelbase | 124 in |
| Overall Length | 19 in |
| Tire Size | 540/65R38 |
| Width Outside Frame | 101 in |
| Track Width | 80 in |
Transmission
| Max Speed | 42.0 mph |
|---|---|
| Transmission Type | 2 range continuously variable |
