JCB
Kubota
L48
Backhoe Loader
Specifications pending
1 / 5
Image 1 of 5
Specifications
34 data points
Operating Specifications
| Fuel Capacity | 11.9 gal |
|---|---|
| Hydraulic System Fluid Capacity | 11.9 gal |
| Cooling System Fluid Capacity | 2.1 gal |
| Tire Size Front - 2wd / 4wd | 7 x 15 |
| Operating Voltage | 12 V |
| Alternator Supplied Amperage | 50 A |
Engine
| Engine Model | 404C-22 |
|---|---|
| Displacement | 134 in³ |
| Power Measured @ | 2,800 rpm |
| Gross Power | 50.0 hp |
| Net Power | 47.0 hp |
| Number of Cylinders | 4 |
| Aspiration | Naturally aspirated |
| Net Max Torque | 104 lb-ft |
Hydraulic System
| Pump Flow Capacity | 12.4 gal/min |
|---|---|
| Relief Valve Pressure | 3,000 psi |
| Pump Type | Hydrostatic |
Dimensions
| Ground Clearance | 11 in |
|---|---|
| Wheelbase | 43 in |
| Transport Length | 134 in |
Transmission
| Max Speed | 7.0 mph |
|---|---|
| Max Speed - Reverse | 7.0 mph |
| Number of Forward Gears | 1 |
| Number of Reverse Gears | 1 |
| Transmission Type | Hydrostatic |
Tires & Wheels
| Rear Tires Size | 7 x 15 |
|---|
Backhoe
| Dig Depth | 101 in |
|---|---|
| Reach From Swivel | 133 in |
| Bucket Dig Force | 4,852 lb |
Loader
| Bucket Capacity | 0.30 yd³ |
|---|---|
| Clearance at Max Dump Height | 83 in |
| Bucket Breakout Force | 5,179 lb |
| Bucket Width | 56 in |
| Dig Depth | 2 in |
