JCB
Kubota
L48
Backhoe Loader
Specifications pending
1 / 5
Image 1 of 5
Specifications
40 data points
Operating Specifications
| Tire Size Front - 2wd / 4wd | 10X16.5 |
|---|---|
| Operating Voltage | 12 V |
| Alternator Supplied Amperage | 50 A |
Engine
| Displacement | 134 in³ |
|---|---|
| Power Measured @ | 2,800 rpm |
| Gross Power | 49.0 hp |
| Net Power | 47.0 hp |
| Number of Cylinders | 4 |
| Aspiration | Natural |
| Torque Measured @ | 2,000 rpm |
| Fuel Type | Replaceable cartridge plus water/sediment separator prefilter |
| Emissions Certification | Stage EC Stage IIIA |
| Net Max Torque | 103 lb-ft |
| Rated Engine Speed | 2,800 rpm |
Hydraulic System
| Pump Flow Capacity | 11.9 gal/min |
|---|---|
| Relief Valve Pressure | 3,000 psi |
Dimensions
| Ground Clearance | 11 in |
|---|---|
| Wheelbase | 43 in |
| Transport Width | 56 in |
| Transport Length | 131 in |
| Height to Top of Suspended Cab | 89 in |
Transmission
| Max Speed | 4.7 mph |
|---|---|
| Max Speed - Reverse | 4.7 mph |
| Transmission Type | Hydrostatic |
Fluid Capacities
| Fuel Tank | 11.9 gal |
|---|---|
| Cooling system | 2.2 gal |
| Engine oil with filter | 2.6 gal |
Tires & Wheels
| Rear Tires Size | 10X16.5 |
|---|
Backhoe
| Max dig depth | 101 in |
|---|---|
| Dig Depth | 101 in |
| Reach From Swivel | 133 in |
Loader
| Reach at Max Dump Height | 17 in |
|---|---|
| Dig Depth | 2 in |
| Dump height | 88 in |
Electrical System
| Alternator | 50 |
|---|---|
| Battery | 72A/hour |
| Front working lights | 2 adjustable |
| Gauges | Fuel Level Hour meter |
| Pre-wire | Beacon |
| Rear working lights | 2 adjustable |
