JCBFuchs
MHL331
Material Handler
23 specifications
1 / 5
Image 1 of 5
Specifications
25 data points
Operating Specifications
| Operating Weight | 45,680 lb |
|---|---|
| Hydraulic System Fluid Capacity | 19.3 gal |
| Fuel Capacity | 81.9 gal |
| Cooling System Fluid Capacity | 5.2 gal |
| Engine Oil Capacity | 5.4 gal |
| Hydraulic Pump Flow Capacity | 58.4 gal/min |
| Hydraulic System Relief Valve Pressure | 4,554 psi |
| Hydraulic Pump Type | Open centred negative control hydraulic system with twin variable flow piston pumps providing flow-on-demand for maximum efficiency. |
| Front Diff Fluid Capacity | 3.7 gal |
| Rear Diff Fluid Capacity | 3.2 gal |
| Oscillating Axle Angle | 9 ° |
Engine
| Engine Model | JCB EcoMAX 444 TCA-99 Eu Stage IIIB EPA Tier 4 interim compliant. |
|---|---|
| Displacement | 269 in³ |
| Number of Cylinders | 4 |
| Engine Type | Water cooled 4-stroke 4-cylinder in-line direct injection turbocharged diesel. |
| Alternator | 55 A |
| Air filter type | Dry element with secondary safety element and in cab warning indicator. |
| Rated Power | 125.0 hp |
Dimensions
| Ground Clearance | 15 in |
|---|---|
| Height - Top of Cab | 132 in |
| Overall Width | 99 in |
| Tail Swing Radius | 93 in |
Transmission
| Max Travel Speed | 15.6 mph |
|---|---|
| Transmission Type | Hydrostatic drive via piston motor and powershift transmission |
Swing Mechanism
| Swing Speed | 6 rpm |
|---|
