DoosanFuchs
MHL331
Material Handler
23 specifications
1 / 5
Image 1 of 5
Specifications
31 data points
Operating Specifications
| Operating Weight w/o Attachment | 57,220 lb |
|---|---|
| Operating Weight | 57,220 lb |
| Hydraulic System Fluid Capacity | 76.6 gal |
| Fuel Capacity | 79.3 gal |
| Cooling System Fluid Capacity | 6.3 gal |
| Engine Oil Capacity | 6.6 gal |
Engine
| Power Measured @ | 1,900 rpm |
|---|---|
| Gross Power | 189.0 hp |
| Net Power | 186.0 hp |
| Engine Make | Doosan |
Hydraulic System
| Pump Capacity | 62.3 gal/min |
|---|---|
| Relief Pressure | 4,786 psi |
Dimensions
| Height - Top of Cab | 128 in |
|---|---|
| Wheelbase | 121 in |
| Shipping Height | 137 in |
| Shipping Length | 376 in |
| Undercarriage Width | 98 in |
| Height to Top of Cab - fixed riser | 128 in |
Transmission
| Max Speed | 22.0 mph |
|---|---|
| Max Travel Speed | 22.0 mph |
Swing Mechanism
| Swing Speed | 11 rpm |
|---|---|
| Swing Torque | 60,785 lb-ft |
Boom/Stick Mobile Excavator Option 1
| Max Digging Depth | 197 in |
|---|---|
| Max Loading Height | 478 in |
| Max Reach Along Ground | 431 in |
| Shipping Height of Unit | 137 in |
| Shipping Length of Unit | 376 in |
Boom/Stick Mat. Handler Option 1
| Boom/Stick Option (MAT) 1 | Boom - 25.6 ft / Arm - 17.7 ft |
|---|---|
| Max Depth | 197 in |
| Max Height | 478 in |
| Max Reach Along Ground | 431 in |
