Fuchs
MHL331
Material Handler
23 specifications
1 / 5
Image 1 of 5
Specifications
22 data points
Operating Specifications
| Operating Weight w/o Attachment | 67,461 lb |
|---|---|
| Hydraulic System Fluid Capacity | 92.5 gal |
| DEF tank capacity | 8.5 gal |
| Gradeability-laden | 40.0 % |
Engine
| Engine Model | Deutz 6.1 L6 |
|---|---|
| Displacement | 372 in³ |
| Power Measured @ | 2,000 rpm |
| Gross Power | 173.0 hp |
| Engine Type | 6-cylinder inline |
| Cooling method | Water and charge air cooling with temperature controlled fan speed |
Hydraulic System
| Maximum operating pressure | 5,221 psi |
|---|
Dimensions
| Ground Clearance | 17 in |
|---|---|
| Wheelbase | 110 in |
| Overall Length | 204 in |
| Overall Width | 108 in |
| Overall Height | 122 in |
| Turning Radius | 328 in |
Transmission
| Max Speed | 11.2 mph |
|---|---|
| Turning radius | 328 in |
Electrical System
| Alternator | — |
|---|---|
| Operation voltage | 24 V |
Wheel Undercarriage
| Steering Angle | 27 ° |
|---|
