Doosan
DX210WMH-5
Material Handler
31 specifications
1 / 5
Image 1 of 5
Specifications
23 data points
Operating Specifications
| Operating Weight w/o Attachment | 53,351 lb |
|---|---|
| Hydraulic System Fluid Capacity | 86.0 gal |
| Fuel Capacity | 69.0 gal |
| DEF tank capacity | 8.5 gal |
| Gradeability-laden | 40.0 % |
Engine
| Engine Model | Deutz TCD 4.1 L4 |
|---|---|
| Displacement | 250 in³ |
| Power Measured @ | 2,000 rpm |
| Gross Power | 154.0 hp |
| Engine Type | 4-cylinder in-line engine |
| Cooling method | Water and charge air cooling with temperature controlled fan speed |
Hydraulic System
| Maximum operating pressure | 5,221 psi |
|---|
Dimensions
| Ground Clearance | 15 in |
|---|---|
| Wheelbase | 98 in |
| Overall Length | 181 in |
| Overall Width | 98 in |
| Overall Height | 121 in |
| Turning Radius | 302 in |
Transmission
| Max Speed | 11.2 mph |
|---|
Swing Mechanism
| Swing Speed | 8 rpm |
|---|
Electrical System
| Alternator | — |
|---|---|
| Operation voltage | 24 V |
Wheel Undercarriage
| Steering Angle | 29 ° |
|---|
