Fuchs
MHL331
Material Handler
23 specifications
1 / 5
Image 1 of 5
Specifications
24 data points
Operating Specifications
| Operating Weight w/o Attachment | 78,263 lb |
|---|---|
| Hydraulic System Fluid Capacity | 120.0 gal |
| Fuel Capacity | 83.0 gal |
| DEF tank capacity | 8.5 gal |
| Gradeability-laden | 39.0 % |
Engine
| Engine Model | Deutz TCD 6.1 L6 |
|---|---|
| Displacement | 372 in³ |
| Power Measured @ | 2,000 rpm |
| Gross Power | 215.0 hp |
| Engine Type | 6-cylinder inline |
| Cooling method | Combi-cooler (coolant/ charge air) with fan speed control system; optional reversing function |
Hydraulic System
| Maximum operating pressure | 5,221 psi |
|---|
Dimensions
| Ground Clearance | 19 in |
|---|---|
| Wheelbase | 109 in |
| Overall Length | 222 in |
| Overall Width | 109 in |
| Overall Height | 137 in |
| Turning Radius | 344 in |
Transmission
| Max Speed | 11.2 mph |
|---|---|
| Turning radius | 344 in |
Swing Mechanism
| Swing Speed | 7 rpm |
|---|---|
| Swing Torque | 59 lb-ft |
Electrical System
| Alternator | — |
|---|---|
| Operation voltage | 24 V |
