JCB
Volvo
ECR145D
Excavator
4 specifications
1 / 5
Image 1 of 5
Specifications
55 data points
Operating Specifications
| Operating Weight | 55,557 lb |
|---|---|
| Fuel Capacity | 90.7 gal |
| Hydraulic Pump Flow Capacity | 114.2 gal/min |
| Hydraulic System Fluid Capacity | 63.7 gal |
| Hydraulic System Relief Valve Pressure | 4,975 psi |
| Engine Oil Capacity | 5.7 gal |
| Cooling System Fluid Capacity | 7.1 gal |
| Swing Drive Fluid Capacity | 1.6 gal |
Engine
| Engine Model | BB-6BGITR8-06 |
|---|---|
| Displacement | 396 in³ |
| Power Measured @ | 2,150 rpm |
| Net Power | 160.0 hp |
| Aspiration | turbocharged |
Dimensions
| Ground Clearance | 19 in |
|---|---|
| Height - Top of Cab | 118 in |
| Length of Track on Ground | 151 in |
| Tail Swing Radius | 119 in |
| Width to Outside of Tracks | 119 in |
| Removal Counterweight Clearance | 44 in |
Undercarriage
| Track Gauge | 95 in |
|---|---|
| Number of Track Rollers per Side | 9 |
| Max Travel Speed | 3.5 mph |
| Shoe Size | 24 in |
| Number of Shoes per Side | 51 |
| Number of Carrier Rollers per Side | 2 |
Boom/Stick Excavator Option 1
| Max Digging Depth | 226 in |
|---|---|
| Max Reach Along Ground | 354 in |
| Max Loading Height | 243 in |
| Max Vertical Wall Digging Depth | 178 in |
| Max Cutting Height | 349 in |
| Shipping Length of Unit | 397 in |
| Shipping Height of Unit | 126 in |
Bucket
| Reference Bucket Capacity | 1.50 yd³ |
|---|---|
| Maximum Bucket Capacity | 2.00 yd³ |
| Minimum Bucket Capacity | 1.10 yd³ |
Swing Mechanism
| Swing Speed | 11 rpm |
|---|
Boom/Stick Excavator Option 2
| Max Digging Depth | 243 in |
|---|---|
| Max Vertical Wall Digging Depth | 211 in |
| Max Cutting Height | 364 in |
| Max Loading Height | 256 in |
| Max Reach Along Ground | 373 in |
| Shipping Length of Unit | 397 in |
| Shipping Height of Unit | 127 in |
Boom/Stick Excavator Option 3
| Max Digging Depth | 268 in |
|---|---|
| Max Cutting Height | 379 in |
| Max Loading Height | 270 in |
| Max Vertical Wall Digging Depth | 245 in |
| Max Reach Along Ground | 395 in |
| Shipping Length of Unit | 393 in |
Boom/Stick Excavator Option 4
| Max Digging Depth | 285 in |
|---|---|
| Max Cutting Height | 389 in |
| Max Reach Along Ground | 415 in |
| Max Loading Height | 278 in |
| Max Vertical Wall Dig Depth | 263 in |
| Shipping Length of Unit | 395 in |
