Case
New Holland
E200SR
Excavator
44 specifications
1 / 5
Image 1 of 5
Specifications
74 data points
Operating Specifications
| Operating Weight | 33,510 lb |
|---|---|
| Arm Breakout Force | 14,837 lb |
| Arm size | 100 in |
Engine
| Engine Model | Isuzu 4 JJ 1X |
|---|---|
| Displacement | 183 in³ |
| Power Measured @ | 2,000 rpm |
| Net Power | 102.0 hp |
| Max Torque | 257 lb-ft |
| Engine Make | Isuzu |
| Stroke | 4 in |
| Bore | 4 in |
| Fuel Type | Requires ultra low-sulfur fuel B5 biodiesel tolerant |
| Emission Tier Level | Tier 4 |
| Fuel injection | Direct injection - electronic |
| Air filter type | Dry type element with warning restriction indicator |
| Fuel Filter | Replaceable full flow spin-on cartridge |
| Oil Filter | Replaceable full flow spin-on cartridge |
Hydraulic System
| Main pump - Maximum flow | 68.2 gal |
|---|---|
| System relief pressure | 50 psi |
Dimensions
| Ground Clearance | 17 in |
|---|---|
| Tail Swing Radius | 61 in |
| Overall Height | 113 in |
| Track Shoe Width | 24 in |
| Cab height | 111 in |
| Track length | 148 in |
| Center to center - idler to sprocket | 120 in |
| Ground pressure | 6 psi |
| Boom length | 182 in |
Transmission
| Max Speed | 3.5 mph |
|---|
Undercarriage
| Track Shoe Width | 24 in |
|---|
Brakes & Steering
| Service brake | SAHR disc - each motor |
|---|---|
| Brakes Type | Mechanical disc |
| Travel control | Dual stage relief or counter balance design |
Fluid Capacities
| Fuel Tank | 52.9 gal |
|---|---|
| Hydraulic system | 41.8 gal |
| Cooling system | 4.4 gal |
| Hydraulic Tank | 19.9 gal |
| Engine oil w/ filter change | 4.5 gal |
| Swing drive | 0.6 gal |
| Final Drive | 0.6 gal |
Boom/Stick Excavator Option 1
| Max Digging Depth | 217 in |
|---|---|
| Max Reach Along Ground | 343 in |
| Max Vertical Wall Digging Depth | 193 in |
| Minimum swing radius | 92 in |
| Max.Dumping Height | 274 in |
| Max Digging Reach on Ground | 322 in |
| Bucket rotation | 178 ° |
| Mximum dig radius | 326 in |
| Dig radius at ground line | 321 in |
| Dump height | 273 in |
General Specifications
| Operating Weight lbs (kg) | 32,100 (14,600) Starting 2025 Model Year |
|---|---|
| Digging Depth ft (m) | 19.8 (6) Starting 2025 Model Year |
| Digging Reach ft. (m) | 28.3 (8.6) Starting 2025 Model Year |
| Engine hp (kW) | 102 (76.4) Starting 2025 Model Year |
Swing Mechanism
| Swing Speed | 13 rpm |
|---|
Boom/Stick Excavator Option 2
| Max Vertical Wall Digging Depth | 209 in |
|---|---|
| Minimum swing radius | 108 in |
| Bucket rotation | 178 ° |
| Dig radius at ground line | 339 in |
| Dump height | 287 in |
| Maximum dig radius | 344 in |
| Maximum reach height | 382 in |
Boom/Stick Excavator Option 3
| Max Digging Depth | 202 in |
|---|---|
| Minimum swing radius | 80 in |
| Overall height | 113 in |
| Bucket rotation | 178 ° |
| Maximum dig radius | 313 in |
| Dig radius at ground line | 306 in |
| Dump height | 262 in |
| Maximum reach height | 357 in |
Performance
| Lift over end Max. reach | 2,756 lb |
|---|---|
| Lift over side Max. reach | 2,756 lb |
| Lift over end 10' radius | 18,409 lb |
| Lift over side 10' radius | 14,352 lb |
