JCB

JS460LC

Excavator

Operating Weight
100,442 lb
Max Digging Depth
354 in
Max Digging Depth
330 in
Net Power
305.0 hp
All excavators
JCB JS460LC Excavator
1 / 5
Image 1 of 5
Image: machineryline.ng

Specifications

59 data points

Operating Specifications

Operating Specifications specifications
Operating Weight100,442 lb
Fuel Capacity172.0 gal
Hydraulic Pump Flow Capacity90.0 gal/min
Hydraulic System Fluid Capacity119.0 gal
Hydraulic System Relief Valve Pressure4,712 psi
Cooling System Fluid Capacity12.6 gal
Operating Voltage24 V
Swing Drive Fluid Capacity2.2 gal
Alternator Supplied Amperage50 A

Engine

Engine specifications
Engine ModelAA-6SDITC
Displacement600 in³
Power Measured @2,000 rpm
Net Power305.0 hp
AspirationTurbocharged

Dimensions

Dimensions specifications
Ground Clearance24 in
Height - Top of Cab130 in
Length of Track on Ground174 in
Tail Swing Radius137 in
Width to Outside of Tracks137 in
Removal Counterweight Clearance54 in

Undercarriage

Undercarriage specifications
Ground Pressure11 psi
Track Gauge110 in
Number of Track Rollers per Side2
Max Travel Speed2.4 mph
Shoe Size28 in
Number of Shoes per Side52
Number of Carrier Rollers per Side9
Drawbar Pull85,318 lb

Boom/Stick Excavator Option 1

Boom/Stick Excavator Option 1 specifications
Max Digging Depth354 in
Max Reach Along Ground509 in
Max Loading Height333 in
Max Vertical Wall Digging Depth291 in
Max Cutting Height456 in
Shipping Length of Unit469 in
Shipping Height of Unit151 in

Bucket

Bucket specifications
Reference Bucket Capacity3.00 yd³
Maximum Bucket Capacity3.00 yd³
Minimum Bucket Capacity1.90 yd³

Swing Mechanism

Swing Mechanism specifications
Swing Speed9 rpm

Boom/Stick Excavator Option 2

Boom/Stick Excavator Option 2 specifications
Max Digging Depth330 in
Max Vertical Wall Digging Depth274 in
Max Cutting Height444 in
Max Loading Height315 in
Max Reach Along Ground483 in
Shipping Length of Unit466 in
Shipping Height of Unit139 in

Boom/Stick Excavator Option 3

Boom/Stick Excavator Option 3 specifications
Max Digging Depth305 in
Max Cutting Height437 in
Max Loading Height307 in
Max Vertical Wall Digging Depth251 in
Max Reach Along Ground462 in
Shipping Length of Unit465 in
Shipping Height of Unit138 in

Boom/Stick Excavator Option 4

Boom/Stick Excavator Option 4 specifications
Max Digging Depth270 in
Max Cutting Height426 in
Max Reach Along Ground432 in
Max Loading Height298 in
Max Vertical Wall Dig Depth220 in
Shipping Length of Unit466 in
