JCB
John Deere
302A
Backhoe Loader
42 specifications
1 / 5
Image 1 of 5
Specifications
24 data points
Operating Specifications
| Operating Voltage | 12 V |
|---|---|
| Max Weight | 8,598 lb |
| Front Axle Fluid Capacity | 1.3 gal |
Engine
| Power Measured @ | 2,800 rpm |
|---|---|
| Aspiration | Naturally aspirated |
Transmission
| Transmission Type | Hydrostatic |
|---|
General Specifications
| Operating Weight lbs (kg) | 8,420 (3,820) Starting 2007 Model Year |
|---|---|
| Max Digging Depth ft. (m) | 10 (3) Starting 2009 Model Year |
| Lift Capacity lbs (kgs) | 3,478 (1,578) Starting 2007 Model Year |
| Loading Height ft (m) | 8.75 (2.7) Starting 2008 Model Year |
| 4th Gear Fwd mph (kmh) | hydrostatic Starting 2007 Model Year |
| Backhoe Loading Height ft. (m) | 8.75 (2.7) Starting 2009 Model Year |
| Travel Speed 4th Gear Fwd MPH (kmh) | hydrostatic Starting 2009 Model Year |
| Breakout Force lbs (kgs) | 5,830 (2,644) Starting 2007 Model Year |
| Digging Depth ft (m) | 10 (3) Starting 2008 Model Year |
| Loader SAE HP (kw) | 50 (37) Starting 2009 Model Year |
| Loader Lift Capacity lbs. (kg) | 3,428 (1,550) Starting 2009 Model Year |
| Loader Breakout Force lbs. (kg) | 5,830 (2,644) Starting 2009 Model Year |
| SAE Net hp (kW) | 48 (37) Starting 2007 Model Year |
| SAE HP (KW) | 50 (37) Starting 2010 Model Year |
| Weight lbs (kg) | 8,421 (3,820) Starting 2010 Model Year |
Backhoe
| Reach From Swivel | 148 in |
|---|---|
| Bucket Dig Force | 13,283 lb |
Loader
| Bucket Width | 73 in |
|---|
