JCB
Wacker Neuson
WL18
Wheel Loader
22 specifications
1 / 5
Image 1 of 5
Specifications
32 data points
Engine
| Engine Model | JCB Diesel by Kohler - KDI 2504 TCR |
|---|---|
| Power Measured @ | 2,200 rpm |
| Gross Power | 64.0 hp |
| Number of Cylinders | 4 |
| Aspiration | Turbocharged |
| Engine Type | 4 stroke Electronic Common Rail |
| Emission level | Stage 3B & T4F |
| Capacity | 0.7 gal |
Weights
| Front axle weight | 6,008 lb |
|---|---|
| Rear axle weight | 7,183 lb |
Hydraulic System
| Pump Flow Capacity | 17.0 gal/min |
|---|---|
| Pump Type | Single Gear Pump |
Dimensions
| Ground Clearance | 13 in |
|---|---|
| Height - Top of Cab | 98 in |
| Wheelbase | 88 in |
| Overall Length | 236 in |
| Width Over Tires | 70 in |
| Hinge Pin - Max Height | 186 in |
| Turning Radius - Inside | 84 in |
| Wheel track | 55 in |
| Center of front axle to counterweight (Pusher) | 50 in |
Transmission
| Max Speed - Forward | 12.5 mph |
|---|---|
| Transmission Type | Hydrostatic |
Fluid Capacities
| Fuel Tank | 21.2 gal |
|---|---|
| Engine Oil | 3.0 gal |
| Hydraulic oil tank | 18.5 gal |
Bucket
| Bucket Capacity - heaped | 1.10 yd³ |
|---|---|
| Bucket Width | 73 in |
Electrical System
| Alternator | — |
|---|---|
| Battery capacity | 100 Ah |
Axles
| Axle oil front | 1.2 gal |
|---|---|
| Axle oil rear | 1.6 gal |
