JCB
New Holland
W110B
Wheel Loader
43 specifications
1 / 5
Image 1 of 5
Specifications
37 data points
Operating Specifications
| Operating Weight | 21,010 lb |
|---|
Engine
| Engine Model | EcoMAX |
|---|---|
| Power Measured @ | 2,200 rpm |
| Gross Power | 145.0 hp |
| Net Power | 135.0 hp |
| Number of Cylinders | 4 |
| Aspiration | Turbocharged-charge cooled |
| Torque Measured @ | 1,500 rpm |
| Engine Make | JCB |
| Capacity | 1.3 gal |
Weights
| Front axle weight | 7,231 lb |
|---|---|
| Rear axle weight | 13,779 lb |
Hydraulic System
| Pump Flow Capacity | 42.3 gal/min |
|---|---|
| Pump Type | Variable displacement piston pump |
Dimensions
| Ground Clearance | 19 in |
|---|---|
| Height - Top of Cab | 111 in |
| Wheelbase | 109 in |
| Overall Length | 277 in |
| Width Over Tires | 94 in |
| Hinge Pin - Max Height | 223 in |
| Turning Radius - Inside | 154 in |
| Dump Height | 174 in |
| Dump reach | 29 in |
| Wheel track | 73 in |
| Center of front axle to counterweight (Pusher) | 69 in |
| Height to top of boom pivot | 78 in |
Transmission
| Max Speed - Forward | 24.9 mph |
|---|---|
| Transmission Type | Powershift |
| Make | JCB |
Fluid Capacities
| Fuel Tank | 42.3 gal |
|---|---|
| Engine Oil | 3.7 gal |
| Transmission | 5.1 gal |
| Hydraulic oil tank | 25.7 gal |
| DEF Tank | 7.7 gal |
| Dropbox | 0.4 gal |
Electrical System
| Alternator | — |
|---|---|
| Battery capacity | 120 Ah |
