JCB

VM132PD

Smooth Drum Roller

Operating Weight
29,542 lb
Max Speed
7.9 mph
Drum Width
83 in
Gross Power
150.0 hp
All smooth drum rollers
JCB VM132PD Smooth Drum Roller
1 / 5
Image 1 of 5
Image: grays.com

Specifications

28 data points

Operating Specifications

Operating Specifications specifications
Operating Weight29,542 lb
Max Speed7.9 mph
Fuel Capacity105.7 gal
Operating Voltage12 V
Hydraulic System Fluid Capacity21.2 gal
Engine Oil Capacity3.8 gal
Alternator Supplied Amperage95 A
Cooling System Fluid Capacity5.1 gal

Engine

Engine specifications
Engine ModelB5.9 - 150C
Displacement359 in³
Power Measured @2,200 rpm
Gross Power150.0 hp
Number of Cylinders6
Aspirationturbocharged

Dimensions

Dimensions specifications
Ground Clearance18 in
Height - Top of Cab117 in
Wheelbase10 in
Width Over Tires90 in
Overall Length w/o Blade226 in

Tires & Wheels

Tires & Wheels specifications
Tires23.1-26/12 Tractor tread

Drum

Drum specifications
Drum Width83 in
Drum Diameter59 in
Vibration Frequency 129 vpm
Nominal Amplitude - High0 in
Centrifugal Force - High42,264 lb
Pad Height4 in
Number of Pads132
Vibratory Frequency 236 vpm
