JCB
Hamm
HD 10 VO
Smooth Drum Roller
40 specifications
1 / 5
Image 1 of 5
Specifications
28 data points
Operating Specifications
| Operating Weight | 9,535 lb |
|---|---|
| Max Speed | 6.8 mph |
| Fuel Capacity | 20.1 gal |
| Operating Voltage | 12 V |
| Hydraulic System Fluid Capacity | 13.3 gal |
| Engine Oil Capacity | 2.6 gal |
| Alternator Supplied Amperage | 45 A |
Engine
| Engine Model | V 2203 |
|---|---|
| Displacement | 134 in³ |
| Power Measured @ | 2,800 rpm |
| Gross Power | 46.6 hp |
| Number of Cylinders | 4 |
Dimensions
| Ground Clearance | 12 in |
|---|---|
| Height - Top of Cab | 101 in |
| Wheelbase | 8 in |
| Overall Length | 9 in |
| Overall Width | 50 in |
| Drum Diameter - Front | 32 in |
Tires & Wheels
| Tires | 8.25 R15 Smooth |
|---|
Drum
| Drum Width | 55 in |
|---|---|
| Drum Diameter | 32 in |
| Vibration Frequency 1 | 50 vpm |
| Nominal Amplitude - High | 0 in |
| Centrifugal Force - High | 11,915 lb |
| Vibration Frequency 2 | 55 vpm |
| Static Linear Load | 7 lb-ft |
| Centrifugal Force - Low | 6,969 lb |
| Nominal Amplitude - Low | 0 in |
