John Deere
135D
- Operating Weight
- 30,737 lb
- Max Digging Depth
- 219 in
- Max Digging Depth
- 238 in
- Net Power
- 93.0 hp
1 / 5
Image 1 of 5
Specifications
46 data points
Operating Specifications
| Operating Weight | 30,737 lb |
|---|---|
| Fuel Capacity | 58.2 gal |
| Hydraulic Pump Flow Capacity | 55.5 gal/min |
| Hydraulic System Relief Valve Pressure | 4,980 psi |
| Engine Oil Capacity | 4.5 gal |
| Cooling System Fluid Capacity | 4.3 gal |
| Operating Voltage | 24 V |
| Swing Drive Fluid Capacity | 0.9 gal |
| Alternator Supplied Amperage | 50 A |
Engine
| Engine Model | 4JJ1X Tier III certified |
|---|---|
| Displacement | 183 in³ |
| Power Measured @ | 2,000 rpm |
| Net Power | 93.0 hp |
| Aspiration | Turbocharged air-to-air charge air cooler |
Dimensions
| Ground Clearance | 18 in |
|---|---|
| Height - Top of Cab | 108 in |
| Length of Track on Ground | 114 in |
| Tail Swing Radius | 59 in |
| Width to Outside of Tracks | 102 in |
| Removal Counterweight Clearance | 35 in |
Undercarriage
| Ground Pressure | 6 psi |
|---|---|
| Track Gauge | 79 in |
| Number of Track Rollers per Side | 7 |
| Max Travel Speed | 3.5 mph |
| Shoe Size | 24 in |
| Number of Shoes per Side | 44 |
| Number of Carrier Rollers per Side | 1 |
| Drawbar Pull | 26,303 lb |
Boom/Stick Excavator Option 1
| Max Digging Depth | 219 in |
|---|---|
| Max Reach Along Ground | 325 in |
| Max Loading Height | 268 in |
| Max Vertical Wall Digging Depth | 198 in |
| Max Cutting Height | 365 in |
| Shipping Length of Unit | 291 in |
| Shipping Height of Unit | 110 in |
Bucket
| Reference Bucket Capacity | 0.71 yd³ |
|---|---|
| Maximum Bucket Capacity | 1.10 yd³ |
| Minimum Bucket Capacity | 0.50 yd³ |
Swing Mechanism
| Swing Speed | 14 rpm |
|---|
Boom/Stick Excavator Option 2
| Max Digging Depth | 238 in |
|---|---|
| Max Vertical Wall Digging Depth | 198 in |
| Max Cutting Height | 379 in |
| Max Loading Height | 283 in |
| Max Reach Along Ground | 344 in |
| Shipping Length of Unit | 292 in |
| Shipping Height of Unit | 110 in |
