John Deere
Caterpillar
570
Processor
18 specifications
1 / 5
Image 1 of 5
Specifications
19 data points
Operating Specifications
| Operating Weight | 50,706 lb |
|---|---|
| Max Speed | 13.7 mph |
| Fuel Capacity | 107.0 gal |
| Operating Voltage | 24 V |
| Alternator Supplied Amperage | 140 A |
| Hydraulic System Fluid Capacity | 37.0 gal |
| Transmission Type | hydrostatic-mechanical two-speed gearbox |
Engine
| Engine Model | 6068HTJ |
|---|---|
| Power Measured @ | 1,900 rpm |
| Gross Power | 182.4 hp |
| Torque Measured @ | 1,400 rpm |
| Max Torque | 575 lb-ft |
Dimensions
| Height - Top of Cab | 151 in |
|---|---|
| Wheelbase | 207 in |
| Overall Width | 118 in |
| Shipping Length - non tilt | 438 in |
| Shipping Length - tilt | 480 in |
Undercarriage
| Ground Clearance | 24 in |
|---|
Boom
| Max Reach w/ Head | 395 in |
|---|
