Caterpillar

570

Processor

Operating Weight
36,332 lb
Gross Power
163.0 hp
Net Power
154.0 hp
All processors/harvesters
Caterpillar 570 Processor
1 / 5
Image 1 of 5
Image: stoparts.com

Specifications

18 data points

Operating Specifications

Operating Specifications specifications
Operating Weight36,332 lb
Max Speed11.2 mph
Fuel Capacity105.7 gal
Hydraulic System Fluid Capacity39.7 gal
Cooling System Fluid Capacity13.3 gal
Transmission TypeFully Hydrostatic
Engine Oil Capacity8.0 gal

Engine

Engine specifications
Engine Model3126 DITA Diesel Engine
Displacement439 in³
Gross Power163.0 hp
Net Power154.0 hp

Dimensions

Dimensions specifications
Height - Top of Cab134 in
Overall Width110 in
Shipping Length - non tilt268 in

Undercarriage

Undercarriage specifications
Ground Clearance48 in

Boom

Boom specifications
Max Reach w/ Head41 in

Drive System

Drive System specifications
Tire Size - front600/65-34 14PR
Tire Size - rear600/65-34 14PR
