570
Processor
18 specifications
1 / 5
Image 1 of 5
Specifications
24 data points
Operating Specifications
| Operating Weight | 37,258 lb |
|---|---|
| Max Speed | 15.6 mph |
| Fuel Capacity | 122.9 gal |
| Operating Voltage | 24 V |
| Alternator Supplied Amperage | 140 A |
| Hydraulic System Fluid Capacity | 51.0 gal |
| Cooling System Fluid Capacity | 10.6 gal |
| Transmission Type | Hydrostatic mechanical with two speed gearbox |
Engine
| Engine Model | 6CT8.3 |
|---|---|
| Displacement | 507 in³ |
| Power Measured @ | 2,100 rpm |
| Gross Power | 218.0 hp |
| Number of Cylinders | 6 |
| Aspiration | Turbocharged |
| Torque Measured @ | 1,500 rpm |
| Max Torque | 643 lb-ft |
Dimensions
| Height - Top of Cab | 144 in |
|---|---|
| Wheelbase | 146 in |
| Overall Width | 113 in |
Undercarriage
| Ground Pressure | 8 psi |
|---|---|
| Ground Clearance | 25 in |
Boom
| Max Reach w/ Head | 339 in |
|---|
Drive System
| Tire Size - front | 700 x 26.5 ELS |
|---|---|
| Tire Size - rear | 700 x 34 TRS |
