John Deere
Yanmar
Ke - 140
Tractor
22 specifications
1 / 5
Image 1 of 5
Specifications
60 data points
Engine
| Engine Model | 3TNV80F-NCJT |
|---|---|
| Displacement | 77 in³ |
| Gross Power | 23.9 hp |
| Number of Cylinders | 3 |
| Aspiration | Natural |
| Bore | 3 in |
| Stroke | 3 in |
| Engine Type | Diesel |
| Air cleaner | Dual element |
| Cooling system | Water pump |
| Rated Engine Speed | 3,200 rpm |
| Emissions compliance | Final Tier 4 |
| Lubrication | Pressurized |
| Fuel tank capacity | 6.3 gal |
| Engine Manufacturer | Yanmar |
| Compression ratio | .95 |
| Family | GYDXL1.27NS1 HYDXL1.27NS1 |
| Engine torque at rated speed | 39 lb-ft |
| Cylinder liners | Cast-In-Block |
| Power take-off (PTO) power | 18.0 hp |
| Injection pump type | Indirect Injection |
Hydraulic System
| Pump Type | Gear |
|---|---|
| Maximum operating pressure | 2,150 psi |
| Remote control valves available | 2 |
| Draft control sensing | Position control |
| Hydraulic Type | Open Center |
| Pump rated output | Steering 13.25 L/min 3.5 gpm Implement 13.25 L/min 3.5 gpm 26.5 L/min 7.0 gpm |
Dimensions
| Wheelbase | 756 in |
|---|---|
| Front Axle Clearance | 13 in |
| Shipping weight | 1,793 lb |
| Turning radius without brakes | 104 in |
| Limited slip differential | No |
Transmission
| Brakes | Wet disc |
|---|---|
| Steering | Power steering |
| Differential lock | Yes |
| Final Drive Type | Spur Gear |
| Cruise control | Standard |
| Axle capacity | Front - 612 kg Rear - 1100 kg |
| Standard transmission; forward/reverse | Hydrostatic - 2 range |
| Creeper | No |
| Left-hand reverser | No |
Fluid Capacities
| Crankcase with filter | 0.7 gal |
|---|
Tires & Wheels
| Rear Tires Size | R3 Turf - 31x13.5-15 R4 Industrial - 12-16.5 R3 Radial - 280/70-R16 |
|---|---|
| Front Tires Size | R3 Turf - 23x8.50-12 R4 Industrial - 23x8.50-12 R3 Radial - 220/55-R12 |
| Front tread range | 38 in |
Electrical System
| Alternator (12-V) | 40 A |
|---|---|
| Battery size | 500 CCA |
| Starter size | 1.6 hp |
3-Point Hitch
| Lift capacity (24-in. behind link arms) | 882 lb |
|---|
Power Take-Off (PTO)
| Standard | Rear - 540 rpm Mid - 2100 rpm |
|---|---|
| Clutch | Wet disc |
| Control | Independent |
| Brake (for mid and rear PTO) | Wet disc |
Final Drive
| Final Drive Type | Spur Gear |
|---|---|
| Differential lock | Yes |
Fuel System
| Fuel System Type | Indirect Injection |
|---|---|
| Fuel consumption | 1.50 gph (5.68 lph) |
Operator Station
| Gear shift location - console/floor | Left Hand Side |
|---|---|
| Platform - flat/straddle | Three-piece semi flat |
| Rollover protective structure | Type Foldable OSHA SAE ASAE |
