Kubota

B7410DT

Tractor

Operating Weight
1,246 lb
Displacement
48 in³
Power Measured @
2,900 rpm
Gross Power
18.0 hp
All tractors
Kubota B7410DT Tractor
1 / 5
Image 1 of 5
Image: lanesharkusa.com

Specifications

25 data points

Operating Specifications

Operating Specifications specifications
Operating Weight1,246 lb
Fuel Capacity3.7 gal
3 Point Hitch Lift Capacity @ 24 inches1,058 lb
3 Point Hitch Typecat. I
Turning Radius79 in
Cooling System Fluid Capacity0.8 gal
Engine Oil Capacity0.7 gal

Engine

Engine specifications
Engine ModelD782-E-D20
Displacement48 in³
Power Measured @2,900 rpm
Gross Power18.0 hp
Number of Cylinders3
AspirationE-TVCS liquid cooled
PTO Power15.0 hp

Hydraulic System

Hydraulic System specifications
Pump Flow Capacity3.9 gal/min

Dimensions

Dimensions specifications
Ground Clearance12 in
Wheelbase60 in
Overall Length8 in
Tire Sizefront 6-12 rear 9.5-16
Width Outside Frame43 in

Transmission

Transmission specifications
Max Speed8.8 mph
Number of Forward Gears6
Transmission Typegear
Number of Reverse Gears2

Axles

Axles specifications
Final Drivespur gear
