John Deere
Thomas
105
Skid Steer Loader
27 specifications
1 / 5
Image 1 of 5
Specifications
25 data points
Operating Specifications
| Operating Weight | 6,165 lb |
|---|---|
| Fuel Capacity | 15.0 gal |
| Operating Voltage | 12 V |
| Alternator Supplied Amperage | 55 A |
| Cooling System Fluid Capacity | 2.8 gal |
Engine
| Engine Model | 3029D |
|---|---|
| Displacement | 179 in³ |
| Power Measured @ | 2,400 rpm |
| Number of Cylinders | 3 |
Hydraulic System
| Pump Flow Capacity | 14.6 gal/min |
|---|---|
| Relief Valve Pressure | 3,100 psi |
| Pump Type | Hydrostatic |
Dimensions
| Ground Clearance | 8 in |
|---|---|
| Height - Top of Cab | 76 in |
| Wheelbase | 43 in |
| Width Over Tires | 65 in |
| Reach at Max Lift and Dump | 29 in |
| Length with Bucket | 126 in |
| Clearance at Max Lift and Dump | 89 in |
| Turning Radius from Center - inc bucket | 79 in |
| Turning Radius from Center - machine rear | 61 in |
| Length w/o Bucket | 103 in |
Loader
| Operating Load Rating | 1,500 lb |
|---|---|
| Tipping Angle | 3,400 ° |
| Breakout Force | 5,500 psi |
