252
Skid Steer Loader
54 specifications
1 / 5
Image 1 of 5
Specifications
28 data points
Operating Specifications
| Operating Weight | 3,880 lb |
|---|---|
| Max Speed | 5.8 mph |
| Fuel Capacity | 12.7 gal |
| Hydraulic System Fluid Capacity | 4.0 gal |
| Tire Size | 27- 8.50 x 15 |
| Operating Voltage | 12 V |
| Alternator Supplied Amperage | 40 A |
| Engine Oil Fluid Capacity | 2.0 gal |
Engine
| Engine Model | 3D84E-1FC |
|---|---|
| Displacement | 87 in³ |
| Power Measured @ | 2,800 rpm |
| Number of Cylinders | 3 |
Hydraulic System
| Pump Flow Capacity | 8.5 gal/min |
|---|---|
| Relief Valve Pressure | 2,031 psi |
| Pump Type | gear pump |
Dimensions
| Ground Clearance | 8 in |
|---|---|
| Height - Top of Cab | 74 in |
| Wheelbase | 32 in |
| Width Over Tires | 48 in |
| Reach at Max Lift and Dump | 18 in |
| Length with Bucket | 109 in |
| Clearance at Max Lift and Dump | 85 in |
| Turning Radius from Center - inc bucket | 64 in |
| Turning Radius from Center - machine rear | 54 in |
Loader
| Bucket Capacity | 0.10 yd³ |
|---|---|
| Operating Load Rating | 957 lb |
| Tipping Angle | 1,874 ° |
| Breakout Force | 2,787 psi |
