John Deere

240 Series II

Skid Steer Loader

Operating Weight
6,165 lb
Max Speed
6.7 mph
All skid steer loaders
John Deere 240 Series II Skid Steer Loader
1 / 5
Image 1 of 5
Image: purplewave.com

Specifications

22 data points

Operating Specifications

Operating Specifications specifications
Operating Weight6,165 lb
Max Speed6.7 mph
Fuel Capacity15.0 gal
Operating Voltage12 V
Operating Speed6.7 mph

Engine

Engine specifications
Engine Model3029D
Displacement179 in³
Power Measured @2,400 rpm
Number of Cylinders3

Hydraulic System

Hydraulic System specifications
Pump Flow Capacity14.6 gal/min
Relief Valve Pressure3,100 psi
Pump TypeHydrostatic

Dimensions

Dimensions specifications
Ground Clearance8 in
Height - Top of Cab76 in
Wheelbase43 in
Width Over Tires65 in
Reach at Max Lift and Dump29 in
Length with Bucket126 in
Length w/o Bucket103 in

Loader

Loader specifications
Operating Load Rating1,500 lb
Tipping Angle3,400 °
Breakout Force5,500 psi
