A35E
Off-Highway Truck
44 specifications
1 / 5
Image 1 of 5
Specifications
41 data points
Operating Specifications
| Fuel Capacity | 71.0 gal |
|---|---|
| Tire Size | 23.5R25 |
| Engine Oil Capacity | 8.0 gal |
| Cooling System Fluid Capacity | 10.0 gal |
| Hydraulic System Fluid Capacity | 21.0 gal |
| Operating Voltage | 24 V |
| Alternator Supplied Amperage | 55 A |
| Transmission Fluid Capacity | 4.2 gal |
Engine
| Engine Model | OM442 |
|---|---|
| Displacement | 920 in³ |
| Power Measured @ | 2,100 rpm |
| Gross Power | 261.0 hp |
| Net Power | 251.0 hp |
| Aspiration | Naturally aspirated |
| Torque Measured @ | 1,300 rpm |
| Max Torque | 723 lb-ft |
Weights
| Total Empty | 42,593 lb |
|---|---|
| Front Axle - empty | 20,150 lb |
| Total Loaded | 102,118 lb |
| Rear Axle - empty | 11,001 lb |
| Front Axle - loaded | 32,165 lb |
| Rear Axle - loaded | 34,756 lb |
| Center Axle - empty | 11,442 lb |
| Center Axle - loaded | 35,197 lb |
Dimensions
| Ground Clearance | 20 in |
|---|---|
| Wheelbase | 162 in |
| Overall Length | 364 in |
| Overall Width | 130 in |
| Overall Height | 135 in |
| Dump Height | 240 in |
| Dump Ground Clearance | 25 in |
Transmission
| Max Speed | 29.0 mph |
|---|---|
| Transmission Type | ZF 6WG 210 countershaft design with integral drop box constantly meshing gears hydraulically actuated multiple-disc clutch electronic control hydrodynamic torque converter with lock-up built-in PTO drive |
| Number of Forward Gears | 6 |
| Number of Reverse Gears | 3 |
Dump
| Rated Payload | 59,524 lb |
|---|---|
| Dump Angle | 65 ° |
| Raise Time | 14.0 s |
| Lower Time | 7.0 s |
| Capacity - Heaped | 22.00 yd³ |
| Capacity - Struck | 17.00 yd³ |
