John Deere
Mecalac
TLB840R
Backhoe Loader
35 specifications
1 / 5
Image 1 of 5
Specifications
47 data points
Operating Specifications
| Operating Weight 4wd | 12,200 lb |
|---|---|
| Operating Weight 2wd | 12,200 lb |
| Fuel Capacity | 28.0 gal |
| Hydraulic System Fluid Capacity | 16.0 gal |
| Cooling System Fluid Capacity | 4.3 gal |
| Tire Size Front - 2wd / 4wd | 11L-158PRI-1A;12-16.58PR |
| Operating Voltage | 12 V |
| Oil System Fluid Capacity | 2.3 gal |
| Alternator Supplied Amperage | 95 A |
| Turning Radius | 144 in |
| Transmission Fluid Capacity | 1.9 gal |
| Max Weight | 12,200 lb |
Engine
| Engine Model | 4039D |
|---|---|
| Displacement | 239 in³ |
| Power Measured @ | 2,200 rpm |
| Gross Power | 63.0 hp |
| Net Power | 60.0 hp |
| Number of Cylinders | 4 |
| Net Max Torque | 172 lb-ft |
Hydraulic System
| Pump Flow Capacity | 24.0 gal/min |
|---|---|
| Relief Valve Pressure | 2,700 psi |
| Pump Type | Gear |
Dimensions
| Ground Clearance | 13 in |
|---|---|
| Wheelbase | 83 in |
| Transport Width | 91 in |
| Transport Length | 270 in |
| Height to Top of Suspended Cab | 106 in |
Transmission
| Max Speed | 20.1 mph |
|---|---|
| Max Speed - Reverse | 18.0 mph |
| Number of Forward Gears | 4 |
| Number of Reverse Gears | 4 |
| Transmission Type | 4-speed helical gear synchronized collar shift with hydraulic reverser |
Tires & Wheels
| Rear Tires Size | 16.9-248PR R4;17.5L-248PR R4 |
|---|
Backhoe
| Dig Depth | 167 in |
|---|---|
| Reach From Swivel | 207 in |
| Dig Depth - Extended | 212 in |
| Load Height - Extended | 154 in |
| Bucket Dig Force | 10,230 lb |
| Reach From Swivel - Extended | 251 in |
| Reach at Load Height - Extended | 292 in |
| Bucket Dig Force - Extended | 10,230 lb |
Loader
| Bucket Capacity | 0.99 yd³ |
|---|---|
| Clearance at Max Dump Height | 107 in |
| Bucket Breakout Force | 6,700 lb |
| Bucket Width | 84 in |
| Reach at Max Dump Height | 30 in |
| Dig Depth | 4 in |
