John Deere
Caterpillar
434E
Backhoe Loader
37 specifications
1 / 5
Image 1 of 5
Specifications
62 data points
Operating Specifications
| Operating Weight 4wd | 16,140 lb |
|---|---|
| Operating Weight 2wd | 13,800 lb |
| Fuel Capacity | 41.0 gal |
| Hydraulic System Fluid Capacity | 24.1 gal |
| Cooling System Fluid Capacity | 5.6 gal |
| Tire Size Front - 2wd / 4wd | 11L-15 SL F-3(8)(12)/12-16.5 NHS SS-1(8) |
| Operating Voltage | 12 V |
| Oil System Fluid Capacity | 3.5 gal |
| Alternator Supplied Amperage | 90 A |
| Transmission Fluid Capacity | 4.0 gal |
| Max Weight | 1,750 lb |
| Rear Axle Fluid Capacity | 4.8 gal |
| Front Axle Fluid Capacity | 1.8 gal |
Engine
| Engine Model | 4045D |
|---|---|
| Displacement | 276 in³ |
| Power Measured @ | 2,000 rpm |
| Net Power | 72.0 hp |
| Number of Cylinders | 4 |
| Aspiration | Natural |
| Net Max Torque | 209 lb-ft |
| Net Torque Rise | 0 |
Hydraulic System
| Pump Flow Capacity | 28.0 gal/min |
|---|---|
| Relief Valve Pressure | 3,625 psi |
| Pump Type | Gear |
Dimensions
| Ground Clearance | 13 in |
|---|---|
| Wheelbase | 84 in |
| Transport Width | 86 in |
| Transport Length | 280 in |
| Height to Top of Suspended Cab | 108 in |
Transmission
| Max Speed | 22.4 mph |
|---|---|
| Max Speed - Reverse | 8.2 mph |
| Number of Forward Gears | 4 |
| Number of Reverse Gears | 4 |
| Transmission Type | Powershift |
Tires & Wheels
| Rear Tires Size | 19.5L-24 R-4(10) |
|---|
General Specifications
| Operating Weight lbs (kg) | 13,800 (6,259) Starting 2007 Model Year |
|---|---|
| Max Digging Depth ft. (m) | 14.3 (4.3) Starting 2009 Model Year |
| Lift Capacity lbs (kgs) | 6,150 (2,789) Starting 2007 Model Year |
| Loading Height ft (m) | 10.9 (3.32) Starting 2007 Model Year |
| 4th Gear Fwd mph (kmh) | 22.4 (36) Starting 2007 Model Year |
| Backhoe Loading Height ft. (m) | 10.9 (3.3) Starting 2009 Model Year |
| Travel Speed 4th Gear Fwd MPH (kmh) | 22.4 (36) Starting 2009 Model Year |
| Breakout Force lbs (kgs) | 8,600 (3,900) Starting 2007 Model Year |
| Digging Depth ft (m) | 14.3 (4.3) Starting 2007 Model Year |
| Loader SAE HP (kw) | 72 (53) Starting 2009 Model Year |
| Loader Lift Capacity lbs. (kg) | 6,150 (2,789) Starting 2009 Model Year |
| Loader Breakout Force lbs. (kg) | 8,600 (3,900) Starting 2009 Model Year |
| SAE Net hp (kW) | 72 (53) Starting 2007 Model Year |
| SAE HP (KW) | 72 (53) Starting 2010 Model Year |
| Weight lbs (kg) | 13,800 (6,259) Starting 2010 Model Year |
Backhoe
| Dig Depth | 172 in |
|---|---|
| Reach From Swivel | 215 in |
| Dig Depth - Extended | 216 in |
| Load Height - Extended | 168 in |
| Reach From Swivel - Extended | 258 in |
| Load Height | 132 in |
Loader
| Bucket Capacity | 1.10 yd³ |
|---|---|
| Clearance at Max Dump Height | 107 in |
| Bucket Breakout Force | 8,498 lb |
| Bucket Width | 86 in |
| Reach at Max Dump Height | 31 in |
| Dig Depth | 6 in |
