434E
Backhoe Loader
37 specifications
1 / 5
Image 1 of 5
Specifications
35 data points
Operating Specifications
| Operating Weight | 14,469 lb |
|---|---|
| Fuel Capacity | 41.0 gal |
| Hydraulic System Fluid Capacity | 23.6 gal |
| Cooling System Fluid Capacity | 8.7 gal |
| Operating Voltage | 12 V |
| Oil System Fluid Capacity | 3.5 gal |
| Max Weight | 13,993 lb |
Engine
| Engine Model | PowerTech E4045HTO86 |
|---|---|
| Displacement | 4 in³ |
| Power Measured @ | 2,000 rpm |
| Net Power | 87.0 hp |
| Net Torque Rise | 0 |
Hydraulic System
| Pump Flow Capacity | 28.0 gal/min |
|---|---|
| Relief Valve Pressure | 3,625 psi |
| Pump Type | Open center single gear |
Dimensions
| Ground Clearance | 13 in |
|---|---|
| Transport Width | 86 in |
| Transport Length | 280 in |
| Height to Top of Suspended Cab | 108 in |
Transmission
| Max Speed | 20.6 mph |
|---|
General Specifications
| Operating Weight lbs (kg) | 14,030 (6,364) Starting 2014 Model Year |
|---|---|
| Max Digging Depth ft. (m) | 14.3 (4.34) Starting 2014 Model Year |
| Backhoe Loading Height ft. (m) | 10.9. (3.33) Starting 2014 Model Year |
| Travel Speed 4th Gear Fwd MPH (kmh) | 20.6 (33.1) Starting 2013 Model Year |
| Loader SAE HP (kw) | 88 (66) Starting 2013 Model Year |
| Loader Lift Capacity lbs. (kg) | 6,600 (2,996) Starting 2014 Model Year |
| Loader Breakout Force lbs. (kg) | 9,350 (4,241) Starting 2013 Model Year |
Backhoe
| Load Height | 131 in |
|---|
Loader
| Bucket Capacity | 0.99 yd³ |
|---|---|
| Lift Capacity | 6,600 lb |
| Clearance at Max Dump Height | 107 in |
| Bucket Breakout Force | 9,352 lb |
| Bucket Width | 86 in |
| Reach at Max Dump Height | 31 in |
| Dig Depth | 6 in |
