434E
Backhoe Loader
37 specifications
1 / 5
Image 1 of 5
Specifications
55 data points
Operating Specifications
| Operating Weight | 14,352 lb |
|---|---|
| Fuel Capacity | 41.0 gal |
| Hydraulic System Fluid Capacity | 23.6 gal |
| Cooling System Fluid Capacity | 8.7 gal |
| Tire Size Front - 2wd / 4wd | 11L-16 F-3 |
| Operating Voltage | 12 V |
| Oil System Fluid Capacity | 3.5 gal |
| Transmission Fluid Capacity | 15.1 gal |
| Max Weight | 13,913 lb |
| Rear Axle Fluid Capacity | 4.8 gal |
Engine
| Engine Model | John Deere PowerTech |
|---|---|
| Displacement | 275 in³ |
| Power Measured @ | 2,000 rpm |
| Net Power | 52.0 hp |
| Aspiration | Turbocharged |
| Torque Measured @ | 1,300 rpm |
| Engine Make | E 4045HT072 |
| Net Max Torque | 224 lb-ft |
| Net Torque Rise | 0 |
Hydraulic System
| Pump Flow Capacity | 31.5 gal/min |
|---|---|
| Relief Valve Pressure | 3,625 psi |
| Pump Type | Open center gear type tandem with unloader |
Dimensions
| Ground Clearance | 13 in |
|---|---|
| Wheelbase | 74 in |
| Transport Width | 86 in |
| Transport Length | 280 in |
| Height to Top of Suspended Cab | 108 in |
Transmission
| Max Speed | 18.6 mph |
|---|---|
| Max Speed - Reverse | 7.5 mph |
| Number of Forward Gears | 4 |
| Number of Reverse Gears | 2 |
| Transmission Type | Full power shift |
Tires & Wheels
| Rear Tires Size | 19.5L-24 R |
|---|
General Specifications
| Operating Weight lbs (kg) | 13,913 (6,311) Starting 2014 Model Year |
|---|---|
| Max Digging Depth ft. (m) | 14.3 (4.34) Starting 2014 Model Year |
| Backhoe Loading Height ft. (m) | 10.9. (3.33) Starting 2014 Model Year |
| Travel Speed 4th Gear Fwd MPH (kmh) | 18.6 (29.9) Starting 2013 Model Year |
| Loader SAE HP (kw) | 70 (52) Starting 2013 Model Year |
| Loader Lift Capacity lbs. (kg) | 6,600 (2,994) Starting 2013 Model Year |
| Loader Breakout Force lbs. (kg) | 9,350 (4,241) Starting 2013 Model Year |
Backhoe
| Dig Depth | 172 in |
|---|---|
| Reach From Swivel | 205 in |
| Dig Depth - Extended | 206 in |
| Load Height - Extended | 158 in |
| Bucket Dig Force | 9,350 lb |
| Reach From Swivel - Extended | 258 in |
| Load Height | 122 in |
| Bucket Dig Force - Extended | 9,500 lb |
Loader
| Bucket Capacity | 1.10 yd³ |
|---|---|
| Lift Capacity | 6,600 lb |
| Clearance at Max Dump Height | 97 in |
| Bucket Breakout Force | 9,350 lb |
| Bucket Width | 86 in |
| Reach at Max Dump Height | 31 in |
| Dig Depth | 6 in |
