Specifications
56 data points
Operating Specifications
| Operating Weight 4wd | 13,500 lb |
|---|---|
| Operating Weight 2wd | 13,500 lb |
| Fuel Capacity | 36.0 gal |
| Hydraulic System Fluid Capacity | 24.0 gal |
| Cooling System Fluid Capacity | 4.3 gal |
| Tire Size Front - 2wd / 4wd | 11L-158PRF3;11L-1612PR F3;12.5/80-1810PR |
| Operating Voltage | 12 V |
| Oil System Fluid Capacity | 2.3 gal |
| Alternator Supplied Amperage | 65 A |
| Turning Radius | 142 in |
| Transmission Fluid Capacity | 3.7 gal |
| Max Weight | 13,500 lb |
| Rear Axle Fluid Capacity | 3.5 gal |
| Front Axle Fluid Capacity | 2.3 gal |
Engine
| Engine Model | 4045T |
|---|---|
| Displacement | 276 in³ |
| Power Measured @ | 2,200 rpm |
| Gross Power | 88.0 hp |
| Net Power | 80.0 hp |
| Aspiration | Turbocharged |
| Net Max Torque | 271 lb-ft |
| Net Torque Rise | 0 |
Hydraulic System
| Pump Flow Capacity | 36.0 gal/min |
|---|---|
| Relief Valve Pressure | 3,000 psi |
| Pump Type | Gear tandem with unloader |
Dimensions
| Ground Clearance | 13 in |
|---|---|
| Wheelbase | 83 in |
| Transport Width | 86 in |
| Transport Length | 282 in |
Transmission
| Max Speed | 24.4 mph |
|---|---|
| Max Speed - Reverse | 27.2 mph |
| Number of Forward Gears | 4 |
| Number of Reverse Gears | 4 |
| Transmission Type | 4-speed helical cut gear collar shift transmission synchronized in all gears with hydraulic reverser |
Tires & Wheels
| Rear Tires Size | 16.9-248PR R4;19.5L-248PR R4 |
|---|
General Specifications
| Operating Weight lbs (kg) | 13,500 (6,123) Starting 2004 Model Year |
|---|---|
| Lift Capacity lbs (kgs) | 6,150 (2,790) Starting 2004 Model Year |
| Loading Height ft (m) | 11.3 (3.43) Starting 2004 Model Year |
| 4th Gear Fwd mph (kmh) | 24 (39) Starting 2004 Model Year |
| Breakout Force lbs (kgs) | 8,900 (4,037) Starting 2004 Model Year |
| Digging Depth ft (m) | 14.5 (4.42) Starting 2004 Model Year |
| SAE Net hp (kW) | 80 (60) Starting 2004 Model Year |
Backhoe
| Dig Depth | 174 in |
|---|---|
| Reach From Swivel | 220 in |
| Dig Depth - Extended | 222 in |
| Load Height - Extended | 169 in |
| Bucket Dig Force | 11,990 lb |
| Reach From Swivel - Extended | 264 in |
| Reach at Load Height - Extended | 305 in |
| Bucket Dig Force - Extended | 12,158 lb |
Loader
| Bucket Capacity | 1.29 yd³ |
|---|---|
| Clearance at Max Dump Height | 134 in |
| Bucket Breakout Force | 8,325 lb |
| Bucket Width | 92 in |
| Reach at Max Dump Height | 36 in |
| Dig Depth | 7 in |
