John Deere
ASV
PT-70
Compact Track Loader
32 specifications
1 / 5
Image 1 of 5
Specifications
31 data points
Operating Specifications
| Operating Weight | 8,558 lb |
|---|---|
| Fuel Capacity | 18.5 gal |
| Operating Voltage | 12 V |
| Alternator Supplied Amperage | 70 A |
Engine
| Engine Model | E 4024HT |
|---|---|
| Displacement | 147 in³ |
| Power Measured @ | 2,300 rpm |
| Gross Power | 68.2 hp |
| Net Power | 63.2 hp |
| Number of Cylinders | 4 |
| Aspiration | Turbocharged |
| Torque Measured @ | 2,000 rpm |
| Engine Make | John Deere |
| Peak Torque | 170 lb-ft |
Hydraulic System
| Pump Flow | 15.6 gal/min |
|---|---|
| Relief Valve Pressure | 3,100 psi |
| Hydraulic Horsepower-Standard Flow | 30.1 hp |
Dimensions
| Ground Clearance | 10 in |
|---|---|
| Height - Top of ROPS/FOPS | 79 in |
| Turning Radius | 79 in |
| Dump Height | 95 in |
| Length - without Bucket | 108 in |
| Dump angle | 42 ° |
| Dump reach | 28 in |
| Hinge pin height, maximum height | 118 in |
Undercarriage
| Ground Pressure | 5 psi |
|---|---|
| Number of Track Rollers per Side | 4 |
Loader
| Operating Load | 1,903 lb |
|---|---|
| Tipping Load | 5,604 lb |
| Bucket Breakout Force | 5,125 lb |
| Boom breakout force | 1,589 lb |
