John Deere
Mustang
2026
Skid Steer Loader
31 specifications
1 / 5
Image 1 of 5
Specifications
39 data points
Operating Specifications
| Operating Weight | 6,605 lb |
|---|---|
| Max Speed | 11.0 mph |
| Hydraulic System Fluid Capacity | 20.1 gal |
| Tire Size | 12 x 16.5 10 PR SKS |
| Operating Voltage | 12 V |
| Alternator Supplied Amperage | 70 A |
Engine
| Engine Model | E 4024HT |
|---|---|
| Displacement | 149 in³ |
| Power Measured @ | 2,300 rpm |
| Number of Cylinders | 4 |
| Aspiration | Turbocharged and intercooled |
| Torque Measured @ | 2,000 rpm |
| Engine Make | John Deere PowerTech |
| Air cleaner | Dry dual element |
| Emissions Certification | EPA Interim Tier 4/EU Stage IIIB |
| Net Torque | 170 lb-ft |
| Net Torque Rise | — |
Hydraulic System
| Pump Flow Capacity | 31.0 gal/min |
|---|---|
| Hydraulic Horsepower-Standard Flow | 38.0 hp |
| Hydraulic Horsepower_High Flow | 46.0 hp |
| System Pressure at Couplers | 3,100 psi |
Dimensions
| Ground Clearance | 10 in |
|---|---|
| Wheelbase | 43 in |
| Reach at Max Lift and Dump | 29 in |
| Height - Top of ROPS/FOPS | 79 in |
| Length w/o Bucket | 108 in |
| Angle of departure | 28 ° |
| Length | 132 in |
| Hinge pin height, maximum height | 119 in |
| Turning Radius - TTS870 | 79 in |
| Overall width without bucket | 69 in |
Loader
| Operating Load Rating | 2,152 lb |
|---|---|
| Operating Width | 69 in |
| Tipping load (ISO 14397) | 4,004 lb |
| Boom breakout force | 3,500 lb |
| Width without Bucket | 70 in |
| Dump height | 96 in |
Axles
| Tractive Effort | 7,100 lb-ft |
|---|---|
| Maximum Axle Torque | 4,725 lb-ft |
