Mustang
John Deere
125
Skid Steer Loader
29 specifications
1 / 5
Image 1 of 5
Specifications
31 data points
Operating Specifications
| Operating Weight | 4,000 lb |
|---|---|
| Max Speed | 6.8 mph |
| Fuel Capacity | 10.3 gal |
| Hydraulic System Fluid Capacity | 10.0 gal |
| Operating Voltage | 12 V |
| Alternator Supplied Amperage | 650 A |
Engine
| Engine Model | 3TNV88 |
|---|---|
| Displacement | 100 in³ |
| Power Measured @ | 2,600 rpm |
| Gross Power | 35.0 hp |
| Number of Cylinders | 3 |
Hydraulic System
| Pump Flow Capacity | 14.5 gal/min |
|---|---|
| Relief Valve Pressure | 2,750 psi |
Dimensions
| Ground Clearance | 6 in |
|---|---|
| Height - Top of Cab | 108 in |
| Wheelbase | 35 in |
| Width Over Tires | 56 in |
| Reach at Max Lift and Dump | 23 in |
| Length with Bucket | 115 in |
| Clearance at Max Lift and Dump | 85 in |
| Turning Radius from Center - inc bucket | 70 in |
| Turning Radius from Center - machine rear | 54 in |
| Length w/o Bucket | 90 in |
General Specifications
| Engine Power HP (KW) | 35 (26) Starting 2016 Model Year |
|---|---|
| Operating Width IN. (CM) | 48.4 (123) Starting 2016 Model Year |
| OPERATING LOAD LBS. (KG) | 1,050 (476) Starting 2016 Model Year |
Loader
| Bucket Capacity | 0.41 yd³ |
|---|---|
| Operating Load Rating | 1,175 lb |
| Tipping Angle | 2,100 ° |
| Operating Width | 48 in |
| Breakout Force | 2,200 psi |
