John Deere
Komatsu
WA50-3
Wheel Loader
36 specifications
1 / 5
Image 1 of 5
Specifications
26 data points
Operating Specifications
| Tire Size | 405/70R20 |
|---|---|
| Operating Voltage | 24 V |
| Alternator Supplied Amperage | 65 A |
| Rated Bucket Capacity | 1.40 yd³ |
Engine
| Engine Model | 5030T |
|---|---|
| Displacement | 177 in³ |
| Net Power | 73.0 hp |
| Number of Cylinders | 5 |
| Aspiration | Turbocharged |
| Max Torque | 195 lb-ft |
| Engine Make | John Deere Power Tech |
| Make | Deere |
| Air cleaner | Dual safety element dry type |
Weights
| Operating Weight | 13,404 lb |
|---|
Hydraulic System
| Pump Flow Capacity | 25.1 gal/min |
|---|---|
| Raise Time | 5.3 s |
| Lower Time | 4.5 s |
| Dump Time | 1.6 s |
Dimensions
| Reach at Max Lift and Dump | 23 in |
|---|---|
| Length with Bucket on Ground | 243 in |
| Hinge Pin - Max Height | 126 in |
Bucket
| Bucket Capacity - heaped | 1.50 yd³ |
|---|---|
| Bucket Capacity - struck | 1.20 yd³ |
| Dump Clearance at Max Raise | 36 in |
| Breakout Force | 12,364 lb |
| Bucket Width | 88 in |
