Yanmar
Case
21D
Wheel Loader
43 specifications
1 / 5
Image 1 of 5
Specifications
20 data points
Operating Specifications
| Operating Weight | 8,411 lb |
|---|---|
| Tire Size | 15.5/60-18-8PR |
| Static Tipping Weight | 5,976 lb |
| Turning Radius | 154 in |
| Rear Axle Oscillation | 8 ° |
Engine
| Engine Model | 4TNV88-BNKAH |
|---|---|
| Displacement | 134 in³ |
| Power Measured @ | 2,500 rpm |
| Gross Power | 40.4 hp |
Hydraulic System
| Pump Flow Capacity | 14.8 gal/min |
|---|---|
| Relief Valve Setting | 3,000 psi |
Dimensions
| Ground Clearance | 12 in |
|---|---|
| Height - Top of Cab | 101 in |
| Width Over Tires | 64 in |
| Length with Bucket on Ground | 174 in |
Transmission
| Max Speed - Forward | 11.8 mph |
|---|---|
| Max Speed - Reverse | 11.8 mph |
| Transmission Type | Hydrostatic |
Bucket
| Bucket Capacity - heaped | 0.71 yd³ |
|---|---|
| Dump Clearance at Max Raise | 96 in |
