Volvo
A35E
Off-Highway Truck
44 specifications
1 / 5
Image 1 of 5
Specifications
41 data points
Operating Specifications
| Fuel Capacity | 106.0 gal |
|---|---|
| Tire Size | 29.5R25 |
| Engine Oil Capacity | 8.9 gal |
| Cooling System Fluid Capacity | 16.9 gal |
| Hydraulic System Fluid Capacity | 36.9 gal |
| Operating Voltage | 24 V |
| Alternator Supplied Amperage | 55 A |
| Transmission Fluid Capacity | 7.3 gal |
Engine
| Engine Model | OM442LA |
|---|---|
| Displacement | 892 in³ |
| Power Measured @ | 2,100 rpm |
| Gross Power | 429.0 hp |
| Net Power | 410.0 hp |
| Aspiration | Turbocharged and aftercooled |
| Torque Measured @ | 1,200 rpm |
| Max Torque | 1,290 lb-ft |
Weights
| Total Empty | 62,722 lb |
|---|---|
| Front Axle - empty | 31,284 lb |
| Total Loaded | 143,190 lb |
| Rear Axle - empty | 15,388 lb |
| Front Axle - loaded | 45,702 lb |
| Rear Axle - loaded | 48,524 lb |
| Center Axle - empty | 16,050 lb |
| Center Axle - loaded | 48,965 lb |
Dimensions
| Ground Clearance | 25 in |
|---|---|
| Wheelbase | 176 in |
| Overall Length | 420 in |
| Overall Width | 133 in |
| Overall Height | 145 in |
| Dump Height | 283 in |
| Dump Ground Clearance | 32 in |
Transmission
| Max Speed | 31.0 mph |
|---|---|
| Transmission Type | Allison HD4560 engine mounted planetary hydraulically actuated multiple-disc clutches electronic control hydrodynamic torque converter with lock-up |
| Number of Forward Gears | 5 |
| Number of Reverse Gears | 1 |
Dump
| Rated Payload | 80,468 lb |
|---|---|
| Dump Angle | 70 ° |
| Raise Time | 19.0 s |
| Lower Time | 10.0 s |
| Capacity - Heaped | 29.00 yd³ |
| Capacity - Struck | 22.00 yd³ |
