John Deere
Kubota
L48
Backhoe Loader
Specifications pending
1 / 5
Image 1 of 5
Specifications
43 data points
Operating Specifications
| Fuel Capacity | 3.5 gal |
|---|---|
| Hydraulic System Fluid Capacity | 20.5 gal |
| Cooling System Fluid Capacity | 3.3 gal |
| Tire Size Front - 2wd / 4wd | 11L-1610ply ratingF3/7.50/8.00-1610ply ratingF3 |
| Operating Voltage | 12 V |
| Oil System Fluid Capacity | 2.3 gal |
| Alternator Supplied Amperage | 35 A |
| Turning Radius | 122 in |
| Transmission Fluid Capacity | 10.0 gal |
Engine
| Engine Model | 300 Series |
|---|---|
| Displacement | 219 in³ |
| Power Measured @ | 2,500 rpm |
| Gross Power | 66.0 hp |
| Net Power | 62.0 hp |
| Number of Cylinders | 4 |
| Torque Measured @ | 1,300 rpm |
| Net Max Torque | 160 lb-ft |
Hydraulic System
| Pump Flow Capacity | 38.0 gal/min |
|---|---|
| Relief Valve Pressure | 2,350 psi |
| Pump Type | Piston constant pressure variable displacement |
Dimensions
| Transport Width | 122 in |
|---|---|
| Transport Length | 285 in |
| Height to Top of Suspended Cab | 102 in |
Transmission
| Max Speed | 16.4 mph |
|---|---|
| Max Speed - Reverse | 18.7 mph |
| Number of Forward Gears | 8 |
| Number of Reverse Gears | 8 |
| Transmission Type | Constant mesh 8-speed forward and reverse.Standard hydraulic direction reverser permits no clutch reversing in all gears |
Tires & Wheels
| Rear Tires Size | 16.9-248ply ratingR4/19.5L-24 8ply ratingR4 |
|---|
Backhoe
| Dig Depth | 185 in |
|---|---|
| Reach From Swivel | 224 in |
| Dig Depth - Extended | 170 in |
| Load Height - Extended | 139 in |
| Bucket Dig Force | 9,650 lb |
| Reach From Swivel - Extended | 224 in |
| Reach at Load Height - Extended | 264 in |
| Bucket Dig Force - Extended | 9,650 lb |
Loader
| Bucket Capacity | 1.29 yd³ |
|---|---|
| Clearance at Max Dump Height | 130 in |
| Bucket Breakout Force | 7,500 lb |
| Bucket Width | 89 in |
| Reach at Max Dump Height | 33 in |
| Dig Depth | 4 in |
