434E
Backhoe Loader
37 specifications
1 / 5
Image 1 of 5
Specifications
47 data points
Operating Specifications
| Fuel Capacity | 23.0 gal |
|---|---|
| Hydraulic System Fluid Capacity | 19.0 gal |
| Cooling System Fluid Capacity | 4.3 gal |
| Tire Size Front - 2wd / 4wd | 11L-1510PRF3;12.00-16.58PRR4 |
| Operating Voltage | 12 V |
| Oil System Fluid Capacity | 2.3 gal |
| Alternator Supplied Amperage | 35 A |
| Turning Radius | 124 in |
| Transmission Fluid Capacity | 3.5 gal |
| Max Weight | 14,400 lb |
Engine
| Engine Model | 4-219D |
|---|---|
| Displacement | 219 in³ |
| Power Measured @ | 2,500 rpm |
| Gross Power | 66.0 hp |
| Net Power | 62.0 hp |
| Number of Cylinders | 4 |
| Aspiration | Naturally aspirated |
| Torque Measured @ | 1,300 rpm |
| Net Max Torque | 156 lb-ft |
| Net Torque Rise | 0 |
Hydraulic System
| Pump Flow Capacity | 30.0 gal/min |
|---|---|
| Relief Valve Pressure | 2,500 psi |
| Pump Type | 8 radial piston closed-center variable flow constant pressure |
Dimensions
| Ground Clearance | 13 in |
|---|---|
| Wheelbase | 83 in |
| Transport Width | 93 in |
| Transport Length | 276 in |
Transmission
| Max Speed | 22.3 mph |
|---|---|
| Max Speed - Reverse | 25.9 mph |
| Number of Forward Gears | 4 |
| Number of Reverse Gears | 4 |
| Transmission Type | Manual shift with first and second speeds having sliding collar engagement and third and fourth speeds engaged in cone-type synchronizers. |
Tires & Wheels
| Rear Tires Size | 19.5L-2410PRR4 |
|---|
Backhoe
| Dig Depth | 174 in |
|---|---|
| Reach From Swivel | 211 in |
| Dig Depth - Extended | 222 in |
| Load Height - Extended | 155 in |
| Bucket Dig Force | 10,200 lb |
| Reach From Swivel - Extended | 259 in |
| Reach at Load Height - Extended | 306 in |
| Bucket Dig Force - Extended | 10,200 lb |
Loader
| Bucket Capacity | 1.29 yd³ |
|---|---|
| Clearance at Max Dump Height | 108 in |
| Bucket Breakout Force | 7,800 lb |
| Bucket Width | 92 in |
| Reach at Max Dump Height | 29 in |
| Dig Depth | 4 in |
