Specifications
38 data points
Operating Specifications
| Fuel Capacity | 34.0 gal |
|---|---|
| Hydraulic System Fluid Capacity | 11.0 gal |
| Cooling System Fluid Capacity | 4.3 gal |
| Tire Size Front - 2wd / 4wd | 11-162PR F3F/12-16.58PR F3 |
| Operating Voltage | 12 V |
| Oil System Fluid Capacity | 2.4 gal |
| Alternator Supplied Amperage | 78 A |
| Turning Radius | 141 in |
| Transmission Fluid Capacity | 11.0 gal |
| Max Weight | 15,600 lb |
| Front Axle Fluid Capacity | 1.8 gal |
Engine
| Engine Model | 4045T |
|---|---|
| Displacement | 276 in³ |
| Power Measured @ | 2,200 rpm |
| Gross Power | 85.0 hp |
| Net Power | 75.0 hp |
| Number of Cylinders | 4 |
| Aspiration | Naturally aspirated or turbocharged |
| Torque Measured @ | 1,300 rpm |
| Net Max Torque | 224 lb-ft |
Hydraulic System
| Pump Type | Naturally aspirated and turbocharged with static and dynamic timing |
|---|
Dimensions
| Ground Clearance | 13 in |
|---|---|
| Wheelbase | 83 in |
| Transport Width | 93 in |
| Transport Length | 282 in |
Transmission
| Number of Forward Gears | 4 |
|---|---|
| Number of Reverse Gears | 4 |
| Transmission Type | Fully synchronized 4-speed with collar shift with hydraulic reverser |
Tires & Wheels
| Rear Tires Size | 19.5-24 10PR R4 |
|---|
Backhoe
| Dig Depth | 185 in |
|---|---|
| Reach From Swivel | 222 in |
| Dig Depth - Extended | 222 in |
| Reach From Swivel - Extended | 258 in |
Loader
| Bucket Capacity | 1.29 yd³ |
|---|---|
| Clearance at Max Dump Height | 108 in |
| Bucket Width | 89 in |
| Reach at Max Dump Height | 30 in |
| Dig Depth | 4 in |
