John Deere
Caterpillar
434E
Backhoe Loader
37 specifications
1 / 5
Image 1 of 5
Specifications
46 data points
Operating Specifications
| Operating Weight 4wd | 18,938 lb |
|---|---|
| Fuel Capacity | 41.0 gal |
| Hydraulic System Fluid Capacity | 25.0 gal |
| Cooling System Fluid Capacity | 5.6 gal |
| Tire Size Front - 2wd / 4wd | 11L-16 12PR/12.5/80-18 10PR |
| Operating Voltage | 12 V |
| Oil System Fluid Capacity | 3.5 gal |
| Alternator Supplied Amperage | 120 A |
| Transmission Fluid Capacity | 4.0 gal |
| Rear Axle Fluid Capacity | 4.8 gal |
| Front Axle Fluid Capacity | 1.8 gal |
Engine
| Engine Model | 4045T |
|---|---|
| Displacement | 276 in³ |
| Power Measured @ | 2,100 rpm |
| Net Power | 96.0 hp |
| Aspiration | Turbocharged |
| Torque Measured @ | 1,500 rpm |
| Net Max Torque | 278 lb-ft |
| Net Torque Rise | 0 |
Hydraulic System
| Pump Flow Capacity | 42.1 gal/min |
|---|---|
| Relief Valve Pressure | 3,625 psi |
| Pump Type | Axial-piston |
Dimensions
| Ground Clearance | 15 in |
|---|---|
| Wheelbase | 84 in |
| Transport Width | 91 in |
| Transport Length | 288 in |
| Height to Top of Suspended Cab | 111 in |
Transmission
| Max Speed | 23.2 mph |
|---|---|
| Max Speed - Reverse | 13.4 mph |
| Number of Forward Gears | 4 |
| Number of Reverse Gears | 3 |
| Transmission Type | Powershift |
Tires & Wheels
| Rear Tires Size | 19.5L-24 10PR |
|---|
Backhoe
| Dig Depth | 193 in |
|---|---|
| Reach From Swivel | 240 in |
| Dig Depth - Extended | 240 in |
| Load Height - Extended | 186 in |
| Bucket Dig Force | 14,801 lb |
| Reach From Swivel - Extended | 284 in |
| Load Height | 152 in |
Loader
| Bucket Capacity | 1.29 yd³ |
|---|---|
| Clearance at Max Dump Height | 101 in |
| Bucket Breakout Force | 10,210 lb |
| Bucket Width | 86 in |
| Reach at Max Dump Height | 36 in |
| Dig Depth | 4 in |
