Specifications
59 data points
Operating Specifications
| Operating Weight | 17,024 lb |
|---|---|
| Operating Weight 2wd | 16,391 lb |
| Fuel Capacity | 41.0 gal |
| Hydraulic System Fluid Capacity | 24.6 gal |
| Cooling System Fluid Capacity | 8.7 gal |
| Tire Size Front - 2wd / 4wd | 14.5/75-16.1 SL F-3 |
| Operating Voltage | 12 V |
| Oil System Fluid Capacity | 3.5 gal |
| Alternator Supplied Amperage | 120 A |
| Transmission Fluid Capacity | 4.0 gal |
| Max Weight | 19,061 lb |
| Rear Axle Fluid Capacity | 4.8 gal |
| Front Axle Fluid Capacity | 1.8 gal |
Engine
| Engine Model | 4045HT063 |
|---|---|
| Displacement | 275 in³ |
| Power Measured @ | 2,000 rpm |
| Net Power | 107.3 hp |
| Aspiration | Turbocharged |
| Torque Measured @ | 1,400 rpm |
| Engine Make | John Deere PowerTech Plus |
| Bore | 4 in |
| Stroke | 29 in |
| Net Max Torque | 317 lb-ft |
| Net Torque Rise | 0 |
Hydraulic System
| Pump Flow Capacity | 42.0 gal/min |
|---|---|
| Relief Valve Pressure | 3,625 psi |
| Pump Type | Pressure compensated load sensing |
Dimensions
| Ground Clearance | 15 in |
|---|---|
| Wheelbase | 74 in |
| Transport Width | 93 in |
| Transport Length | 278 in |
| Height to Top of Suspended Cab | 111 in |
Transmission
| Max Speed | 25.0 mph |
|---|---|
| Max Speed - Reverse | 13.2 mph |
| Number of Forward Gears | 5 |
| Number of Reverse Gears | 3 |
| Transmission Type | 5 speed helical-cut gears full PowerShift |
Tires & Wheels
| Rear Tires Size | 21L-24 R-4 |
|---|
General Specifications
| Operating Weight lbs (kg) | 16,391 (7,435) Starting 2014 Model Year |
|---|---|
| Max Digging Depth ft. (m) | 15.8 (4.83) Starting 2014 Model Year |
| Backhoe Loading Height ft. (m) | 12.5 (3.81) Starting 2014 Model Year |
| Travel Speed 4th Gear Fwd MPH (kmh) | 20.4 (32.8) Starting 2013 Model Year |
| Loader SAE HP (kw) | 107 (80) Starting 2013 Model Year |
| Loader Lift Capacity lbs. (kg) | 7,200 (3,269) Starting 2013 Model Year |
| Loader Breakout Force lbs. (kg) | 10,300 (4,672) Starting 2013 Model Year |
Backhoe
| Dig Depth | 181 in |
|---|---|
| Reach From Swivel | 238 in |
| Dig Depth - Extended | 240 in |
| Load Height - Extended | 187 in |
| Bucket Dig Force | 15,230 lb |
| Reach From Swivel - Extended | 285 in |
| Load Height | 151 in |
Loader
| Bucket Capacity | 1.40 yd³ |
|---|---|
| Lift Capacity | 7,200 lb |
| Clearance at Max Dump Height | 97 in |
| Bucket Breakout Force | 10,300 lb |
| Bucket Width | 92 in |
| Reach at Max Dump Height | 30 in |
| Dig Depth | 7 in |
