John Deere
Caterpillar
434E
Backhoe Loader
37 specifications
1 / 5
Image 1 of 5
Specifications
25 data points
Operating Specifications
| Fuel Capacity | 34.0 gal |
|---|---|
| Hydraulic System Fluid Capacity | 21.5 gal |
| Cooling System Fluid Capacity | 4.8 gal |
| Tire Size Front - 2wd / 4wd | 14.5/75-16.1 10PR F3 |
| Operating Voltage | 12 V |
| Alternator Supplied Amperage | 35 A |
| Transmission Fluid Capacity | 21.5 gal |
| Max Weight | 14,180 lb |
Engine
| Engine Model | 300 Series |
|---|---|
| Displacement | 270 in³ |
| Power Measured @ | 2,500 rpm |
| Net Power | 80.0 hp |
| Number of Cylinders | 4 |
| Aspiration | Naturally aspirated |
| Torque Measured @ | 1,300 rpm |
| Net Max Torque | 202 lb-ft |
Hydraulic System
| Pump Flow Capacity | 28.5 gal/min |
|---|---|
| Relief Valve Pressure | 2,400 psi |
| Pump Type | Close-center |
Dimensions
| Transport Width | 84 in |
|---|---|
| Transport Length | 295 in |
Transmission
| Number of Forward Gears | 8 |
|---|---|
| Number of Reverse Gears | 4 |
| Transmission Type | Powershift |
Tires & Wheels
| Rear Tires Size | 18.4-288/12PR R4 |
|---|
