John Deere
Kawasaki
50ZV
Wheel Loader
47 specifications
1 / 5
Image 1 of 5
Specifications
43 data points
Operating Specifications
| Operating Weight | 29,139 lb |
|---|---|
| Fuel Capacity | 78.8 gal |
| Front Axle/Diff Fluid Capacity | 4.8 gal |
| Rear Axle/Diff Fluid Capacity | 4.8 gal |
| Rated Bucket Capacity | 4.00 yd³ |
Engine
| Engine Model | PowerTech PVS 6068 |
|---|---|
| Displacement | 415 in³ |
| Net Power | 163.0 hp |
| Engine Make | John Deere |
| Make | Deere |
| Torque Rise | 45.0 % |
| Torque | 504 lb-ft |
| Alternator | 100 A |
| System Voltage | 24 V |
| Rated Speed | 1,800 rpm |
| Transmission Type | Powershift |
| Emission level | Tier 4 |
| Engine Output-Net | 162.3 hp |
| Pump | Piston |
Weights
| Operating Weight | 35,008 lb |
|---|
Dimensions
| Height - Top of Cab | 128 in |
|---|---|
| Wheelbase | 117 in |
| Width Over Tires | 101 in |
| Reach at Max Lift and Dump | 57 in |
| Length with Bucket on Ground | 293 in |
| Hinge Pin - Max Height | 151 in |
| Turning Circle | 482 in |
Transmission
| Pump Flow | 50.0 gal/min |
|---|---|
| System Pressure | 252 psi |
Fluid Capacities
| Hydraulic Tank | 31.4 gal |
|---|---|
| Transmission | 5.7 gal |
| Heaped Capacity | 3.10 yd³ |
Bucket
| Bucket Capacity - Smallest | 3.10 yd³ |
|---|---|
| Dump Clearance at Max Raise | 109 in |
| Breakout Force | 22,300 lb |
| Largest bucket capacity | 4.50 yd³ |
Driveline
| Ride control system | Optional |
|---|---|
| Parking Brake Type | Wet Multi Disc - Driveline |
| Service Brake - Location | Axle Inboard |
| Service Brake Actuation | Hydraulic |
| Service Brake Type | Wet Disc |
| Tire size - Standard | 20.5 R25 |
| Differential lock | Front- Locking Rear- Open |
