Kawasaki
New Holland
W110B
Wheel Loader
43 specifications
1 / 5
Image 1 of 5
Specifications
47 data points
Operating Specifications
| Operating Weight | 17,505 lb |
|---|---|
| Fuel Capacity | 31.8 gal |
| Tire Size | 17.5x25-12PR (L-2) |
| Hydraulic System Fluid Capacity | 22.5 gal |
| Static Tipping Weight | 14,837 lb |
| Operating Voltage | 24 V |
| Turning Radius | 205 in |
| Engine Oil Fluid Capacity | 3.0 gal |
| Rear Axle Oscillation | 24 ° |
| Alternator Supplied Amperage | 50 A |
| Front Axle/Diff Fluid Capacity | 4.8 gal |
| Rear Axle/Diff Fluid Capacity | 4.8 gal |
| Cooling System Fluid Capacity | 10.5 gal |
| Transmission Fluid Capacity | 5.3 gal |
| Rated Bucket Capacity | 1.80 yd³ |
Engine
| Engine Model | B4.5T |
|---|---|
| Displacement | 274 in³ |
| Power Measured @ | 2,100 rpm |
| Net Power | 96.0 hp |
| Number of Cylinders | 4 |
| Aspiration | natural |
| Torque Measured @ | 1,500 rpm |
| Make | Cummins |
Weights
| Operating Weight | 17,500 lb |
|---|
Hydraulic System
| Pump Flow Capacity | 27.0 gal/min |
|---|---|
| Raise Time | 6.0 s |
| Lower Time | 3.0 s |
| Dump Time | 1.2 s |
| Relief Valve Setting | 3,000 psi |
| Pump Type | gear type |
Dimensions
| Ground Clearance | 17 in |
|---|---|
| Height - Top of Cab | 124 in |
| Wheelbase | 103 in |
| Width Over Tires | 90 in |
| Reach at Max Lift and Dump | 39 in |
| Length with Bucket on Ground | 240 in |
| Hinge Pin - Max Height | 138 in |
Transmission
| Max Speed - Forward | 21.1 mph |
|---|---|
| Max Speed - Reverse | 21.1 mph |
| Transmission Type | full power shift |
| Number of Forward Gears | 3 |
| Number of Reverse Gears | 3 |
Bucket
| Bucket Capacity - heaped | 1.90 yd³ |
|---|---|
| Bucket Capacity - struck | 1.60 yd³ |
| Dump Clearance at Max Raise | 108 in |
| Breakout Force | 14,330 lb |
| Bucket Width | 94 in |
