RG80
Motor Grader
39 specifications
1 / 5
Image 1 of 5
Specifications
54 data points
Operating Specifications
| Max Operation Weight - Total | 21,703 lb |
|---|---|
| Max Operation Weight - Front Axle | 6,775 lb |
| Max Operation Weight - Rear Axle | 14,928 lb |
| Std Operation Weight - Total | 20,225 lb |
| Tire Size | 13.00-24 |
| Fuel Capacity | 50.0 gal |
| Std Operation Weight - Front Axle | 5,725 lb |
| Std Operation Weight - Rear Axle | 14,500 lb |
| Hydraulic System Fluid Capacity | 14.0 gal |
| Tandem Case Fluid Capacity (each) | 5.0 gal |
| Operating Voltage | 24 V |
| Cooling System Fluid Capacity | 5.6 gal |
| Alternator Supplied Amperage | 42 A |
| Circle Gearbox Fluid Capacity | 1.5 gal |
| Oil System Fluid Capacity | 3.0 gal |
Engine
| Engine Model | 6059D |
|---|---|
| Displacement | 359 in³ |
| Power Measured @ | 2,300 rpm |
| Number of Cylinders | 6 |
| Aspiration | Natural |
| Torque Measured @ | 1,300 rpm |
| Max Power | 90.0 hp |
| Net Power Gears 7-8 | 90.0 hp |
| Net Torque Gears 7-8 | 250 lb-ft |
Hydraulic System
| Pump Flow | 27.0 gal/min |
|---|---|
| Pump Type | Pressure Controlled Variable Displacement |
Dimensions
| Wheelbase | 209 in |
|---|---|
| Overall Length | 293 in |
| Width Over Tires | 96 in |
| Height to Top of Isomount Cab | 122 in |
| Blade Base | 93 in |
| Tandem Axle Wheelbase | 57 in |
| Front Ground Clearance | 24 in |
Transmission
| Max Speed - Forward | 21.6 mph |
|---|---|
| Max Speed - Reverse | 7.1 mph |
| Number of Gears - Forward | 8 |
| Number of Gears - Reverse | 4 |
| Transmission Type | Power Shift |
Moldboard
| Moldboard Height | 22 in |
|---|---|
| Moldboard Width | 144 in |
| Moldboard Thickness | 1 in |
| Side Shift Left | 31 in |
| Side Shift Right | 27 in |
Circle
| Max Lift Above Ground | 13 in |
|---|---|
| Max Reach Outside Tires - Left | 77 in |
| Max Reach Outside Tires - Right | 72 in |
| Diameter | 54 in |
| Blade Tip Angle - Front | 32 ° |
| Rotation | 360 ° |
Front Axle
| Wheel Lean | 20 ° |
|---|---|
| Oscillation - Total | 30 ° |
| Ground Clearance | 24 in |
Steering System
| Turning Radius | 216 in |
|---|---|
| Articulation Angle | 22 ° |
